Setting Up A Device On Windows - Code CORTEXJPOS CR6000 User Manual

9.0 - Setting Up a Device on Windows

Once you have run the installation and configured your reader appropriately, you are ready to setup the barcode scanner on your system. During
installation, the CortexJPOS Device Manager was installed. The Device Manager is used to setup a barcode scanning device for use with JPOS
applications. It can be found in the start menu under the "CortexJPOS" folder.
To setup a USB device, make sure your device is plugged in, and open the CortexJPOS Device Manager program. As long as you've scanned the
USB configuration barcode in section 6.0, the program will automatically detect the device and ask you if you want to configure it. Click "Yes".
The barcode reader will appear in the list of available USB devices. After you click "Apply" and follow the prompts to setup the reader, it will
appear in the list on the left like in this screen:
To setup a serial device, open the CortexJPOS Device Manager program, click "Device", and then click "Refresh". Then select "Serial" from the
"Port Mode" dropdown.
The port number should be "COM x(8200)", where 'x' is the port number, for CR8200, CR950, or CR1500. All other readers should use "COM
x". Once you click "Apply", the serial device will appear in the device list on the left.
10
D008733_02 CortexJPOS User Manual
