Zotac Xbox EK71080 User Manual

E series original mini pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Xbox EK71080 and is the answer not in the manual?

Questions and answers

Related Manuals for Zotac Xbox EK71080

Summary of Contents for Zotac Xbox EK71080

  • Page 2 ZOTAC. Products and corporate names mentioned in this manual may not be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.

  • Page 3: Table Of Contents

    Safety information ----------------------------------------------------------------------------------------------4 Setting up your system -------------------------------------------------------------------------------------4 Care during use ----------------------------------------------------------------------------------------------4 Welcome -----------------------------------------------------------------------------------------------------------5 Package contents -------------------------------------------------------------------------------------------5 Getting to know your ZOTAC ZBOX ----------------------------------------------------------------------6 Front view -----------------------------------------------------------------------------------------------------6 Rear view ------------------------------------------------------------------------------------------------------7 Installing Hardware inside ZOTAC ZBOX ---------------------------------------------------------------8 Installing a memory module -------------------------------------------------------------------------------9...

  • Page 4: Product Specifications

    ZOTAC ZBOX Product Specifications q Microprocessor support v Intel Core i7-7700HQ (quad-core 2.8 GHz, up to 3.8 GHz) q Operating systems: v Supports Windows 8.1 32/64-bit and Windows 10 32/64-bit q System Memory support v Two DDR4-2400/2133 SODIMM slots (Up to 32GB) q Onboard Serial ATA v SATA 6.0 Gb/s transfer rates...

  • Page 5: Safety Information

    ZOTAC ZBOX Safety information Your ZOTAC ZBOX is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before operating your system.

  • Page 6: Welcome

    ZOTAC ZBOX Welcome Congratulations on your purchase of the ZOTAC ZBOX. The following illustration displays the package contents of your new ZOTAC ZBOX. If any of the below items is damaged or missed, contact your retailer. Package contents • 1 x ZOTAC ZBOX •...

  • Page 7: Getting To Know Your Zotac Zbox

    ZOTAC ZBOX Getting to know your ZOTAC ZBOX Front view Refer to the diagram below to identify the components on this side of the system 1. Power switch The power switch allows powering ON and OFF the system. The ring LED can be disabled in BIOS setting.

  • Page 8: Rear View

    ZOTAC ZBOX Rear view Refer to the diagram below to identify the components on this side of the system. 1. WiFi antenna connectors The WiFi antenna connector supports WiFi antenna module. 2. USB 3.0 ports The USB 3.0 port supports the SuperSpeed USB 3.0 devices and is backwards compatible with USB 2.0/1.1 devices.

  • Page 9: Installing Hardware Inside Zotac Zbox

    ZOTAC ZBOX Installing Hardware inside ZOTAC ZBOX Before installing hardware, please follow the instructions below to remove the cover of your ZOTAC ZBOX. 1. Remove the thumb screws. 2. Gently remove the cover as shown below.

  • Page 10: Installing A Memory Module

    2. Gently press down on the memory module until it locks into place by the arms of the memory slot. Note: 1. This ZOTAC ZBOX accomodates two DDR4 SO-DIMM memory modules. You must install at least one module in one of the two slots. 2. 8GB memory is pre-installed in Plus and Windows versions.

  • Page 11: Removing The Memory Module

    ZOTAC ZBOX Removing the memory module 1. Locate the SO-DIMM memory slot and gently press the two arms securing the memory module outwards, as shown in the image below, to release the memory module. 2. Remove the memory module from the slot at a 45-degree angle.

  • Page 12: Installing A Hard Drive

    ZOTAC ZBOX Installing a hard drive 1. Locate the 2.5-inch SATA hard drive and the hard drive bracket. 2. Install the hard drive to the hard drive bracket. *1 TB 2.5-inch SATA hard drive is pre-installed in Plus and Windows versions.
  • Page 13 ZOTAC ZBOX 3. Insert the hard drive into the slot at a 45 degree angle and gently slide into the connector. 4. Secure the installed drive with a thumb screw.

  • Page 14: Installing M.2 Ssd Module

    ZOTAC ZBOX Installing M.2 SSD module 1. Locate the M.2 SSD slot and insert an M.2 SSD module into the slot at a 45 degree angle. 2. Gently press down on the M.2 SSD module, and install the screw. *120GB M.2 SSD is pre-installed in Plus and Windows versions.

  • Page 15: Installing Optane Memory Module

    ZOTAC ZBOX Installing Optane memory module 1. Locate the Optane memory slot and remove the screw from the bolt. 2. Insert an Optane memory module into the slot at a 45 degree angle. 3. Gently press down on the Optane memory module, and install the screw.

  • Page 16: Setting Up Your Zotac Zbox

    ZOTAC ZBOX Setting up your ZOTAC ZBOX You need to connect peripherals before using your ZOTAC ZBOX.
  • Page 17 Connect two supplied AC adapters to the DC IN jack on the system rear panel and then press the power switch on the front panel to turn on the system.  When your ZOTAC ZBOX is not in use, unplug the power adapter or switch off the AC outlet to save on power consumption.

  • Page 18: Installing Drivers And Software

    Install system drivers to gain full functionality of the ZOTAC ZBOX hardware and features. Installing system drivers Before you can use the full features of the ZOTAC ZBOX, the system drivers must be installed. The following types of operating systems are supported by the ZOTAC ZBOX driver DVD and USB flash drive: •...

  • Page 19: Using Your Zotac Zbox

    Note: If you want to use high-amperage USB charging for smartphones and tablets, please install the driver USB Charger driver.  Each driver must be installed individually to ensure proper operation of the ZOTAC ZBOX. Select the driver you want to install. The driver installer should launch.

  • Page 20: Configuring Audio Output

    ZOTAC ZBOX Configuring audio output Follow the steps below to enable audio output when connecting the ZOTAC ZBOX to a TV or receiver via DP/HDMI/DVI adapter. Access the Sound settings via the system Control Panel. Under Playback devices, click the display device that corresponds with your audio compatible display.

  • Page 21: Intel ® Optane Tm Technology

    ZOTAC ZBOX Intel Optane technology ® Intel Optane is a new ultra-high-speed memory technology with 3D XPoint memory media, ® compatible with NVMe storage protocol. The program SetupOptaneMemory.exe is included in the driver DVD and USB flash drive (X:\ OptaneMemory\SetupOptaneMemory.exe).
  • Page 22 ZOTAC ZBOX...
  • Page 23 ZOTAC ZBOX...
  • Page 24 ZOTAC ZBOX...
  • Page 25 ZOTAC ZBOX Restart the system, the following dialog box will display. Click “Yes”. When the Intel Optane Memory interface displays, click “Enable”. ®...
  • Page 26 ZOTAC ZBOX...
  • Page 27 ZOTAC ZBOX Click “Restart” to complete enabling the Optane Memory. When the Optane Memory is successfully enabled, the created Intel Optane ® information will show in Device Manager > Disk drivers.

  • Page 28: Disabling Intel ® Optane Tm Memory

    ZOTAC ZBOX Disabling Intel Optane memory ® Double-click the Intel icon in the lower right corner of the desktop. When the Intel Optane Memory interface displays, click “Disable”. ®...
  • Page 29 ZOTAC ZBOX Click “Restart” to complete disabling the Optane Memory. When the Optane Memory is successfully disabled, the disabled Intel Optane ® information will show in Device Manager > Disk drivers. 291-MB360-02...

This manual is also suitable for:

Xbox ek7107t
