2008 Ducati Desmosedici Z-Fi Installation Instructions
P/N F143
WARNING!
USE ONLY IN RACE OR OTHER CLOSED COURSE APPLICATIONS AND NEVER ON PUBLIC ROADS
Z-Fi products do not meet California CARB highway requirements
Parts List:
Z-Fi Control Unit
Mounting Bracket
Fuel Harness
Download Z-Fi Mapper Software & Its Instructions from Website
USB Cable
O2 Eliminators (2)
Scotchlok (2)
Swingarm Stickers
Read through all instructions before beginning installation. This is not a replacement for the ECU.
This document is intended for use by qualified technicians. For more specific stock component identifition
and location information refer to a factory service manual.
To create the ideal map(s) we recommend using the optimal Z-AFM self-tuning module
15330 Fairfield Ranch Rd., Unit E, Chino Hills, CA 91709 Phone (909) 597-8300 Fax (909)597-5580
www.Bazzaz.net
