Philips CoolSkin HS8440 Service Manual

Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
General:
- Rechargeable
- World wide automatic voltage selection
- Washable
- Charge indication
- Battery low indcation
- Battery full indication
- Travel lock
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 Volt / 50 - 60 Hz
- Shaving heads : HS85
- Charging time : 1.5 hours
- Shaving time : 40 minutes
- SAP coding : HS8440
Published by Philips Consumer Lifestyle
09/02
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
- Remove shaving unit, to prevent damaging during
repairing.
- Remove the 2 screws on top of the schaver.
- Remove the additive tubes and the IM cap.
REPAIR INSTRUCTION
Cleaning shaving heads
- Turn head clockwise and take off.
- Take cutter out and clean it with the brush.
- Place cutter back.
- Place head back and fix it by turning the head
anticlockwise.
OPTIONAL (accessories)
- Pouch : 4222 036 14360
Printed in the Netherlands
2
1
© Copyright reserved
Shaver
HS8440
CoolSkin
Subject to modification
