Specifications - Seastar Solutions Autopilot Pump Operating Instructions Manual

WARNING
DO NOT exceed peak operating
pressure. 1000psi.
4.15" (106mm)
4.78" (122mm)
Figure 2.
NOTICE
Autopilot Pump

SPECIFICATIONS

12V SEASTAR
AUTOPILOT PUMP
• 12 Volts
• 1000psi MAX system
pressure
• Flow Rate (No-Load):
Type 1: 60in /min
3
Type 2: 100in /min
3
• Typical current draw
(up to 300 psi):
Type 1: 4–8A
Type 2: 5–11A
• Cylinder Capacity:
Type 1: 4.9–12.5in
3
Type 2: 12.5–21in
3
6.63"
(168mm)
To assist with the installation, a mounting template is provided on
page 25.
24V SEASTAR
AUTOPILOT PUMP
• 24 Volts
• 1000psi MAX system
pressure
• Flow Rate (No-Load):
Type 1: 60in /min
3
Type 2: 100in
• Typical current draw
(up to 300 psi):
Type 1: 2–4A
Type 2: 3–6A
• Cylinder Capacity:
Type 1: 4.9–12.5in
Type 2: 12.5–21in
4.61" (117mm)
/min
3
3
3
5
