Summary of Contents for Semtech TSDMTX-19V3-EVM
- Page 1 TSDMTX-19V3-EVM Wireless Charging Transmitter WIRELESS CHARGING User Guide LinkCharge™ 20 Series Wireless Charging Generation (V3) Transmitter www.semtech.com...
-
Page 2: Table Of Contents
The objective of this User Guide is to provide a fast, easy and thorough method to fully test and evaluate the Semtech solutions for wireless charging systems. Semtech offers a range of solutions to meet the needs of a wide range of system developers. -
Page 3: Wireless Charging Concepts
5- to 15-watt range, include handheld devices, such as cell phones, tablets, and medical electronics. High power systems support devices such as power tools, radio controlled (“RC”) devices such as drones, and other equipments requiring 15 to 100 watts of power. www.semtech.com User Guide Rev 2.0 2 of27 May-18 TSDMTX-19V3-EVM Semtech... -
Page 4: Product Description
There are a number of other Semtech Receiver EVMs that support different power levels and output voltages, any of which can be used as they are compatible with Qi standard and therefore are compatible with the TSDMTX- 19V3-EVM transmitter. - Page 5 Whenever the receiver is removed from the target area, the transmitter returns to the standby state, searching for another transaction to begin. Apply Power Startup Sequence 1/2 sec - off - Standby (ping…) Charging if FOD Blinking Blinking Solid Charge Complete if Error Solid Green Receiver Removed www.semtech.com User Guide Rev 2.0 4 of27 May-18 TSDMTX-19V3-EVM Semtech...
-
Page 6: Standard Use
Standard Use The TSDMTX-19V3-EVM is easy to set up and use. Use the power supply module and line cord that comes with the EVM kit to apply power to the EVM via “J2”, the 19V power input jack. Once input power is provided, the green LED should light for about a half-second and then turn off. - Page 7 EVM Receiver Tests Additional testing can be performed with the use of an EVM receiver module. There are a number of Semtech Receiver EVMs that support different power levels and output voltages, any of which can be used, as all support the Qi standard and therefore are compatible with the TSDMTX-19V3-EVM transmitter.
- Page 8 The following information is provided for reviewing how the EVM works in detail, as what can be observed below is entirely managed by the Semtech TS80003 Wireless Controller. It allows the observer an opportunity to see how the receiver and transmitter actively manage the wireless power process.
- Page 9 83% at nominal power level (19V/1.0A), assuring good efficiency and minimal heat dissipation concerns. Rx is Semtech TSDMRX-19V/20W-EVM which can support up to 20W load under normal condition. Efficency VS current www.semtech.com...
- Page 10 Thermal Images Using TSDMRX-19V20W-EVM under 19V 20W condition Operation ambient temperature: 26.5°C Rx: 60.6°C Tx board: 54.1°C Thermal Images Using TSDMRX-5V10W-EVM under 5V 10W condition Rx board: 46°C Tx board:43°C www.semtech.com User Guide Rev 2.0 9 of 27 May-18 TSDMTX-19V3-EVM Semtech...
-
Page 11: Firmware Management
GUI for TS80003 allows you install the latest firmware to your board, and also to interrogate the board as to which version of the firmware is currently installed. Here is the link in the Semtech website to download TS8000X GUI file, Docs&... - Page 12 Connect the USB-to-UART adapter board to EVM board, and connect the adapter board to PC. Figure 3 The wire connection of Semtech adapter and TS80003-based EVM 4. Run Wilreless Power GUI to start the user interface, click “Device”, choose “TS80003”.
- Page 13 6. If the status is connected, click “Firmware”, and then click the browse button. Figure 6 Firmware upload window in the GUI Choose the binary file, and click “Open”. Figure 7 Firmware selection window in the GUI. www.semtech.com User Guide Rev 2.0 12 of27 May-18 TSDMTX-19V3-EVM Semtech...
- Page 14 8. Click “Program”, wait until the new window shows “Firmware is programmed successfully”. (The programming process takes almost 20s.) 9. Close the GUI software, and then disconnect the USB-to-UART adapter board with EVM board. www.semtech.com User Guide Rev 2.0 13 of 27 May-18 TSDMTX-19V3-EVM Semtech...
-
Page 15: Fod Test
If the FOD is still present, the transaction will fail again, and continue to do so until the FOD is removed from the target area. www.semtech.com User Guide Rev 2.0 14 of27 May-18 TSDMTX-19V3-EVM Semtech... -
Page 16: Documentation
A. Block Diagram The TSDMTX-19V3-EVM may be divided into a number of sub-blocks as shown in the diagram below: 19 Volt Supply - the external ‘brick’ that converts AC power to 19 volts 5 Volt Buck – based on the TS30011, converts 19 vdc to 5 vdc Controller –... -
Page 17: Schematic
B. Schematic Below are the schematics for the TSDMTX-19V3-EVM. Annotation has been added to indicate which part of the block diagram each component is a member of. www.semtech.com User Guide Rev 2.0 16 of27 May-18 TSDMTX-19V3-EVM Semtech... - Page 18 User Guide Rev 2.0 17 of 27 May-18 TSDMTX-19V3-EVM Semtech...
- Page 19 2, 3, 4 5, 6, 7 2, 3, 4 5, 6, 7 www.semtech.com User Guide Rev 2.0 18 of27 May-18 TSDMTX-19V3-EVM Semtech...
-
Page 20: Bill Of Materials "Bom
C. Bill Of Materials “BOM” Below is a list of the parts used in the TSDMTX-19V3-EVM. An excel spreadsheet file with this information is available on the Semtech website as an additional convenience. Item Designator Qt. ManufacturerCode Footprint Description Manufacturer... - Page 21 1.2.2 or higher as a receiver; 2. Current sense resistor (R11) should be 1% 75PPM/C or better. Coil size 53mmX53mm TSDMRX-19V20W-EVM coil specification: Vendor Part Number Inductance DCR(typ.) Dimension ABRACON AWCCA-RX350300-101 25uH±10% 0.15Ω Ø35.00x3.15mm www.semtech.com User Guide Rev 2.0 20 of27 May-18 TSDMTX-19V3-EVM Semtech...
-
Page 22: Board Layout
E. Board Layers The TSDMTX-19V3-EVM PCB is based on a four layer design as shown below. The ground plane in layer two is recommended to reduce noise and signal crosstalk. All components are placed on the top of the board for easier evaluation of the system. - Page 23 Top Layer Ground Plane www.semtech.com User Guide Rev 2.0 22 of27 May-18 TSDMTX-19V3-EVM Semtech...
- Page 24 Connect the current-sense amplifer using Kelvin connections directly to the Current sense resistor pads, and DO NOT allow high current to flow through the Kelvin connections. It is an example for the layout. www.semtech.com User Guide Rev 2.0 23 of 27 May-18 TSDMTX-19V3-EVM Semtech...
- Page 25 User Guide Rev 2.0 24 of27 May-18 TSDMTX-19V3-EVM Semtech...
-
Page 26: Faqs
Q: What if my questions weren’t answered here? A: Please visit the Semtech website as described on the next page. An updated FAQ for the TSDMTX-19V3-EVM is maintained there and may contain the answers you’re looking for. Your local Semtech FAE can also assist in answering your questions. -
Page 27: Next Steps
There you can find the downloadable copies of the schematic, BOM, and board artwork, as well as additional information on how to obtain Semtech wireless power products, from the chip level all the way to complete board modules, as your needs require. -
Page 28: Contact Information
Information relating to this product and the application or design described herein is believed to be reliable, however such information is provided as a guide only and Semtech assumes no liability for any errors in this document, or for the application or design described herein. Semtech the latest relevant information before placing orders and should verify that such information is current and complete.
