SkyLink 38 User Instructions

PROGRAMMING THE TRANSMITTER

Thank you for your purchase of the Skylink garage door remote
control, Model 38. There are 3 different steps you need to setup
in order to use this universal garage door remote control to operate
your existing garage door opener. These 3 steps are:
1) Frequency switch – select the correct frequency according to
the brand of your existing garage door opener.
2) Brand jumper – place the brand jumper at the correct position
according to the brand of your existing garage door opener.
3) Code setting – Set the jumper connectors on the Model 38 so
that they match the code setting of your existing garage door
opener.
Please follow the detailed instructions below in order to setup the
Skylink Model 38 to work with your existing opener.
After setting up the Model 38, you can activate the remote by pressing
and holding the button for approximately 2 seconds. This is to
avoid accidentally pressing the button and activating the garage
door opener.
3a. The code connector (see diagram D) If the connector is placed on the top and
has 12 columns of posts, each column middle posts, that column is set on " + "
has 3 posts. Each column contains
or "ON" or "CLOSE". If the con-nector is
one connector (see diagram E) for a
placed on the middle and bottom posts,
total of 12 connectors.
that column is set on " - " or "OFF" or
"OPEN". If the connector is removed
completely, (not placed on any posts),
it is set to " 0 " or the neutral position.
(see diagram F for examples of how to
set a column to the three different posi-
tions). When removing a connector to
Diagram D
set a column to the neutral position,
save the connector in case you change
the code at a later date.
Diagram E
1
STEP - SET FREQUENCY SWITCH
1a. Locate frequency 1b. Determine the brand of your garage door
switch on the top of
opener and set the frequency switch to the
the transmitter:
corresponding position. (See chart 1)
(See diagram A)
Set switch
Brand of your opener to position
®
Chamberlain 1983-1997
A
®
Lift-Master 1983-1997 A
®
Sears 1983-1997 A
®
Wayne Dalton 1983-1997
D/A
®
Master Mechanic 1983-1997
A
A B C D
®
Genie (9 positions) 1983-1997 A
®
Genie (12 positions) 1983-1997 A
®
Pulsar/Allister/Allstar 1985-2002
B
®
Master Craft 1985-1997 -
®
Linear 1975-1997 C
®
M-O-M 1983-1997
C
Diagram A
®
Skylink (SL310) 1993-2002
C
®
Skylink (SL300) 1993-2002 D
®
A B C D Stanley 1976-1997 D
®
Multi-Code 1976-1997
D/C
USA 390 318 310 300 ®
Martec/Teckey 1992-2002 D
®
Skylink UR-100 A
CANADA 390 318 315 310
Chart 1
3
STEP - SET CODE CONNECTORS
3b. There are 2 ways to pro-
'-' or 'OFF' or 'OPEN'
'+' or 'ON' or CLOSE '0' = BLANK
Diagram F
2a. To program the model
38, open the case with
a coin. (See diagram B)
USA CANADA
Set switch
Frequency to position Frequency
390 C/A
315/390
390 C/A
315/390
390
C/A 315/390
300/390
C/A 315/390
390 C/A
315/390
390 C/A
315/390
390
C/A 315/390
318 B
318
- C/A
315/390
310 D 310
310
D 310
Diagram B
310 D
310
300 -
-
300
D 310
300/310 D
310
300 -
-
390 A 390
3c. To move the connectors,
gram the model 38 so slide an opened paper clip
into the side of a connector
that it will communicate
and lift. (see diagram G)
with your garage door
When repositioning con-
opener. Open your exist-
nectors, place a connec-
ing transmitter, (the unit
tor on the two chosen posts,
you currently use to open
then push down on the
your garage), or look at
connector with your finger.
the back of your garage
door opener. If you see a
Paper
column of small switches
Clip
go to point 3c in this
manual. If there are no
switches, go to point 3e.
Diagram G
2
STEP - SET BRAND JUMPER
2b. The model 38 transmitter
contains 8 brand jumpers
(see diagram C) and 12
code connectors. (See
diagram D).
Diagram C
Code connector Location
2c. The brand jumper has 8
columns of posts, each
column has 2 posts. (see
diagram C). The connector,
(see diagram E), must be
placed in one of the eight
columns.
1 2 3 4 5 6 7 8
Brand Jumper
Code connector setting to match your opener/motor
Linear (1975-1997) Position 1 to 8
M-O-M (1983-1997) Position 1 to 8
Stanley (310) Canada (1976-1997) Position 1 to 10
Stanley (300) (1976-1997) Position 1 to 10
Multi-Code (1976-1997) Position 1 to 10
Chamberlain (1983-1997) Position 1 to 9
Lift-Master (1983-1997) Position 1 to 9
Sears (1983-1997) Position 1 to 9
Wayne Dalton (1983-1997) Position 1 to 9
Master Mechanic (1983-1997) Position 1 to 9
Genie (9 positions) (1983-1997) Position 1 to 9
Genie (12 positions) (1983-1997) Position 1 to 12
Master Craft (1985-1997) Position 1 to 12
Martec/Teckey (1992-2002) Position 1 to 10
Pulsar/Allister/Allstar (1985-2002) Position 1 to 9
Skylink (SL300/SL310) (1993-2002) Position 1 to 8
To set the brand jumper, deter-
mine the brand of your garage
door opener and place the jum-
per connector to the corres-
ponding position. (See chart 2)
Brand of Use Jumper
your opener Number
®
Linear
1
®
M-O-M 1
®
Stanley 2
®
Multi-Code 2
®
Chamberlain 3
®
Lift-Master
3
®
Sears 3
®
Wayne Dalton 2/3
®
Master Mechanic
3
®
Genie (9 positions) 4
®
Genie (12 positions)
5
®
Master Craft (12 positions) 5
®
Martec/Teckey 6
®
Pulsar / Allister/Allstar
7
®
Skylink (SL300/SL310) 8
Chart 2
+ OR -
+ OR -
+ OR - 11,12 set to '+' or '-'
+ OR - 11,12 set to '+' or '-'
+ OR - 11,12 set to '+' or '-'
+, 0 (blank), OR -
+, 0 (blank), OR -
+, 0 (blank), OR -
+, 0 (blank), OR -
+, 0 (blank), OR -
+ OR -
+ OR -
+ OR -
+ OR - 11,12 set to '+'
+, 0 (blank), OR -
+, 0 (blank), OR - 1-5 set '+' or '0'
6-8 set '0' or '-'
9-12 must set to'0'
