Foscam FI8904W Quick Installation Manual

Quick Installation Guide

（For Windows & Mac OS）
Outdoor IP Camera
Model:FI8904W Model:FI8905W Model:FI8906W
Model:FI8905E Model:FI8919W
V1.7
EQ890411
CE Certi cate Website:
http://www.foscam.com/company/ce-certi cate.html
ShenZhen Foscam Intelligent Technology Co., Ltd
www.foscam.com

Package Contents

IP Camera Power Adapter Resource CD Ethernet Cable
Quick Installation Guide
（For Windows & Mac OS）
Outdoor IP Camera
Model:FI8904W Model:FI8905W Model:FI8906W
Model:FI8905E Model:FI8919W
Mounting Bracket Wi-Fi Antenna Quick Installation Guide Warranty Card
(except FI8919W) (except FI8905E)
Security Warning
Foscam cameras and NVRs require good security
practices to safeguard your privacy. You should
regularly change your camera or NVR password which is
8-10 numbers, letters, symbols combination.
You should update your camera or NVR regularly. Make
sure your camera or NVR has the latest rmware
installed for your speci c model and better experience.
3

Access the Camera

1. Enable the DHCP feature of your router (Enabled by default normally),
then open the Equipment Search Tool program. It should display the
camera's IP address in your LAN (Local Area Network).
2. Double click the camera list here, and your default browser will open
up to the camera's login page.
Default user name
is admin with no
password.
3. When you log in for the rst time, it will request that you modify the
default username and/or password . Input the New username, New
password and Con rm the password, click Con rm to complete the
modi cation. You will now use the new username and password to log
in to the camera in the future.
1
Hardware Introduction
Physical Description
Antenna
LAN
LENS
Power
Infrared LED
Reset Button
Differences
PoE(Power over
Model Wireless Pan/Tilt
Ethernet)
FI8904W
√ × ×
FI8905W √ × ×
FI8905E
× √ ×
FI8906W
√ × ×
FI8919W
√ × √
Hardware Connection
WPS
1. Mount the antenna and make it stand vertically(only for the device
with external antenna).
2. Connect the camera to the LAN network (router or switch) via
ethernet cable.
3. Connect the power adapter to the camera.
Note：
There are three login methods. According to the gure prompted,
choose a di erent login mode.
If you use IE browser,
select this login mode.
If you use Firefox, Google
Chrome, Safari, select this
login mode.
If you use Mobile phone,
select this login mode.
2

Software Installation

1. Insert the CD into the CD drive of your computer.
2. Go to the folder "Equipment Search Tool" and nd the folder "For
Windows OS"or "For Mac OS". Copy and paste the Equipment Search
Tool le to your computer, or drag it onto your Desktop.
Note:
If your computer doesn't have CD drive, you can download the
Equipment Search Tool from our website for free.
4. Take Microsoft Internet Explorer as an example.For the rst time
login the camera,please make sure to install ActiveX when prompted.
Click this button and install
the ActiveX .
Click Run .
5. Click Run button, and re-login the camera, you can see the live
video on the interface.
