Rextron NAVAVIEW KNV102 User Manual

Copyright 03/2001 Rextron Technolgy, Inc.
----------------- Operations ----------------- ----------------- ----------------- Operations Operations Operations
Front Panel operation
You may switch to a different computer by pressing the
front panel push-button directly or by issuing hot-key
commands. The front-panel red indicator changes to
reflect the computer port selected. The indicator flashes
while in either Auto Scan or Manual Scan mode.
Hot-key commands
Hot-key command is a short keyboard sequence to
select a computer, to activate computer scan, etc.
NovaView interprets keystrokes for hot-keys all the time.
A hot-key sequence starts with two left Ctrl keystrokes
followed by one or two more keystrokes.
buzzer generates a high-pitch beep for correct hot-key
command; otherwise, one low-pitch beep for error and
the bad key sequence will not be forwarded to the
selected computer.
To select a computer:
left Ctrl + left Ctrl + 1
Selects the computer at port 1.
left Ctrl + left Ctrl + 2
Selects the computer at port 2
Do not use the keypad at the right of the
keyboard.
To start Auto Scan, automatically scan power-
1 1 1 1
A built-in
