USER MANUAL for RM05/BGE; RM05/BG (T) E-A
Remote controller specifications
Rated Voltage
Lowest Voltage
Effective Distance
Operation Condition
Performance Features
1. Operating Mode: COOL HEAT DRY FAN and AUTO.
2. Timer Setting Function in 24 hours.
3. Indoor Setting Temperature Range: 17°C ~30°C.
4. LCD (Liquid Crystal Display) of all functions.
5. Night Light Function
1.2.1 Parts name
Model
3.0V(2 pieces of LR03 7# batteries)
R05/BGE; RM05/BG (T) E-A
2.4V
8M~11M
-5℃~60℃
AUTO
TE MP
C O O L
SET
DRY
1
1
SET
H E AT
F AN
3
MOD E
M
5
7
AIR DIRE CTI ON
SWIN G
SW IN G
O K
8
EC O
12
13
15
Control System
2
4
FAN
S P EED
6
9
C LOC K
10
TIME ON
TI ME OF F
11
14
1 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midea R05/BGE
Summary of Contents for Midea R05/BGE
- Page 1 Control System USER MANUAL for RM05/BGE; RM05/BG (T) E-A Remote controller specifications Model R05/BGE; RM05/BG (T) E-A Rated Voltage 3.0V(2 pieces of LR03 7# batteries) Lowest Voltage 2.4V Effective Distance 8M~11M Operation Condition -5℃~60℃ Performance Features 1. Operating Mode: COOL HEAT DRY FAN and AUTO.
- Page 2 Control System (1) Mode Button Once pressing, running mode will be selected in the following sequence: AUTO → COOL → → HEAT → Notes: No heating mode for cool only type unit. (2) FanSpeed Fan speed will be selected in following sequence once pressing this button: AUTO →...
- Page 3 Control System (14)OK button Used to confirm the time setting and modification. (15)COOL/HEAT (inner located) Press this button with a needle of 1mm to shift mode between COOL only and COOL&HEAT. During setting, backlight will be lightened. Factory default mode is COOL &HEAT. (16)ECO Button Activate or turn off economic operation mode.
