Quick Installation Guide

ICF-1800

HD Touch Screen Android Multimedia

Conference Phone

VERIFY THE CONTENTS INSIDE THE PACKAGE BOX

The package should contain the following items plus ICF-1800. If any item is missing or damaged, please contact the seller immediately.

Quick Guide

Handset

Step 1. Handset Connection

Plug one end of the handset cord into the handset and the other end into the handset jack.

Step 2. Connecting Power System

The ICF-1800 can be powered either by its external AC/DC adapter or by connecting to an IEEE802.3af/at PSE device such

as 802.3af injector / hub or 802.3af/at PoE switch.

Once the ICF-1800 is powered, the LCD screen will prompt for POST.

NOTE :

Only Internet port supports PoE

Handset Cord

PoE

RJ45 Cable

PoE

Power Adapter

Stand

Handset

PoE

PoE Switch
