Eemax, Inc.™ Electric Tankless Water
INSTALLATION INSTRUCTIONS & OWNER'S MANUAL
When installing or using any high voltage electrical appliance, basic safety precautions should always be
followed. Under no circumstance should you attempt to clean, install, inspect, repair, disassemble or
otherwise service this water heater, without first shutting off all power to the unit directly at the circuit
breaker box. SERIOUS BODILY INJURY OR DEATH COULD OCCUR IF YOU IGNORE THIS WARNING.
THIS PRODUCT SHOULD BE INSTALLED BY A QUALIFIED ELECTRICIAN AND A QUALIFIED PLUMBER IN
ACCORDANCE WITH ALL NATIONAL, STATE, PROVINCIAL AND LOCAL ELECTRICAL & PLUMBING CODES.
PLEASE READ THESE INSTRUCTIONS THOROUGHLY AND COMPLETELY PRIOR TO INSTALLATION & USE.
FAILURE TO DO SO COULD CAUSE PROPERTY DAMAGE, SERIOUS INJURY, OR DEATH.
This manual should be given to the owner after installation and should be retained for future reference.
Tested and certified by the Water Quality Association against NSF/ANSI 372 for lead free
compliance.
Recognize this symbol as an indication of Important Safety Information!
DO NOT
destroy this manual. Please read carefully and keep it in a safe place for future reference
Heaters
HotMax™
HM013240
IMPORTANT SAFETY INFORMATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HotMAx HM013240 and is the answer not in the manual?

Questions and answers

Summary of Contents for EemaX HotMAx HM013240

  • Page 1 Eemax, Inc.™ Electric Tankless Water Heaters INSTALLATION INSTRUCTIONS & OWNER’S MANUAL HotMax™ HM013240 IMPORTANT SAFETY INFORMATION When installing or using any high voltage electrical appliance, basic safety precautions should always be followed. Under no circumstance should you attempt to clean, install, inspect, repair, disassemble or otherwise service this water heater, without first shutting off all power to the unit directly at the circuit breaker box.
  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING DANGER! WATER TEMPERATURE SAFETY SETTING Safety and energy conservation are factors to be considered when selecting the water temperature setting of water heater’s thermostat. This product is subject to water temperatures above 120°F (49°C) which can cause severe burns or death from scalding.
  • Page 3: Table Of Contents

    ABOUT YOUR HOTMAX Congratulations on the purchase of your HotMax! You have purchased the most technologically-advanced electric tankless water heater on the market today designed to produce an endless amount of near boiling hot water instantly. Your new electric tankless water heater features advanced water flow rate and temperature sensors designed to modulate power to the heating elements to maintain a user-selected output water temperature between 140°F (60°C) and 200°F (93°C) (subject to incoming water temperature).
  • Page 4: 1- Before Installation

    1- BEFORE INSTALLATION PLEASE READ THESE INSTRUCTIONS THOROUGHLY AND COMPLETELY PRIOR TO INSTALLATION & USE. FAILURE TO FOLLOW INSTRUCTIONS COULD CAUSE PROPERTY DAMAGE, SERIOUS PERSONAL INJURY, OR DEATH. By installing this product, you acknowledge the terms of the manufacturer’s warranty. Once the heater is installed, do not return product to the place of purchase.
  • Page 5: 3- Mounting Your Water Heater

    Alternatively, you may install an active water leak detector and shutoff valve designed to turn off your water supply in the event that a leak is ever detected. 3- MOUNTING YOUR WATER HEATER Your HotMax should be secured to the mounting surface with 4 screws (minimum 1”...
  • Page 6 Notice: Before drilling any holes, manufacturer recommends dry fitting the installation to make sure the proprietary copper tube reaches both the intended dispenser location and heater.  Pre-drill three holes in the locations specified on the mounting template (Figure 2). ...
  • Page 7: 4- Dispenser/Plumbing Installation

    4- DISPENSER/PLUMBING INSTALLATION Please follow all plumbing and dispenser instructions carefully. We recommend that this product be installed by a licensed and qualified plumber in accordance with all applicable national, state, provincial, and local plumbing codes. DO NOT install HotMax with a different dispenser or outlet hot water pipe that is not included in packaging.
  • Page 8 PLUMBING INSTALLATION INSTRUCTIONS STEP 1: Thoroughly flush and check that all water lines are free of debris. Tighten the proprietary 20” 4 mm copper HOT WATER line that is connected to the dispenser to the OUTLET located on the left side of the heater when facing HotMax.
  • Page 9 IMPORTANT NOTES: 1. We recommend a metallic brass drain, tailpiece and p-trap as plastic (PVC) cannot withstand temperautres greater than 140 °F. 2. Do not solder any pipes with the unit connected to pipes – heat from soldering may damage the flow sensor.
  • Page 10: 5- Electrical Installation

    5- ELECTRICAL INSTALLATION WARNING Manufacturer recommends that this product be installed by a licensed and qualified electrician in accordance with all applicable national, state, provincial, and local electrical codes. As with all electrical appliances, under no circumstances should you attempt to install, repair or disassemble this water heater without first shutting off all power to the unit directly at the fuse or breaker box.
  • Page 11 STEP 3: A separate 8 AWG ground (green wire) conductor for the incoming circuit is required. Route the ground wire along the same path as Line 1 and Line 2. Using a Philips head screwdriver, tighten the ground wire to the ground lead.
  • Page 12: 6- General Operating Instructions

    6- GENERAL OPERATING INSTRUCTIONS Operating your new tankless water heater is similar to using any traditional water heating system. However, HotMax endlessly produces near boiling hot water instantly without dropping in temperature over time so it is very important that you carefully read all of the setup procedures and operating instructions and tips to ensure the maximum performance and energy savings from your new water heater.
  • Page 13: 7- Maintenance

    To ensure maximum performance of your water heater and to reduce the risk of a water leak, we recommend the following maintenance: Remove the Eemax Steam Shield steam separating aerator (Patent Pending) once a month and soak in white vinegar to descale any buildup. Perform this maintenance more often in heavy use or if the supply water is very hard (hardness >...
  • Page 14: 8- Trouble Shooting Guide

    8- TROUBLE SHOOTING GUIDE Are you having problems with your water heater? Please call or email our customer service and technical support team for any help you may need. TOLL FREE 1-(800) Email: 543-6163 Support@eemaxinc.com The following table represents some of the most common technical support questions we receive. Before calling us, please read thoroughly to see if your question or problem is addressed.
  • Page 15: 9- User Interface

    9- USER INTERFACE HotMax Features: HotMax is designed for a flow rate of 0.5 gpm. An acceptable range is 0.4 – 0.6 gpm. Flow rates outside this range will negatively impact the outlet water temperature and the flow pattern from the dispenser. The temperature control knob adjust water temperature in increments of 5°F ...
  • Page 16 NOTES EX07200-82 Rev: C...
