INSTALLATION GUIDE AND OWNER'S MANUAL
MODELS
COVERED:
READ THE GENERAL SAFETY SECTION AND THE ENTIRE MANUAL BEFORE
INSTALLING OR OPERATING THIS WATER HEATER. FAILURE TO FOLLOW
THE SAFETY RULES MAY CAUSE THE UNIT TO OPERATE IMPROPERLY,
WHICH COULD LEAD TO DEATH, SERIOUS BODILY INJURY AND/OR
PROPERTY DAMAGE. READ THE ENCLOSED WARRANTY CARD. WARRANTY
OF THIS WATER HEATER WILL DEPEND ON PROPER INSTALLATION AND
OPERATION. THE WARRANTY SHALL BE VOID IF THE DESIGN HAS BEEN
ALTERED. THE MANUFACTURER OF THIS HEATER WILL NOT BE LIABLE FOR
ANY DAMAGES BECAUSE OF FAILURE TO COMPLY WITH THE INSTALLATION
ANY DAMAGES BECAUSE OF FAILURE TO COMPLY WITH THE INSTALLATION
AND OPERATING INSTRUCTIONS OUTLINED ON THE FOLLOWING PAGES.
THIS UNIT HAS TWO INDEPENDANT DEDICATED POWER CIRCUITS.
DISCONNECT BOTH POWER CIRCUITS BEFORE SERVICING.
THE INSTALLATION MUST CONFORM TO THE INSTRUCTIONS IN
THIS MANUAL; ELECTRIC COMPANY RULES; AND LOCAL CODES, OR IN
THE ABSENCE OF LOCAL CODES, WITH THE LATEST EDITION OF THE
NATIONAL ELECTRICAL CODE. THESE PUBLICATIONS ARE AVAILABLE FROM
YOUR LOCAL GOVERNMENT, PUBLIC LIBRARY, OR ELECTRIC COMPANY.
IF YOU REQUIRE ANY HELP OR HAVE ANY QUESTIONS RELATING TO THE
INSTALLATION OR PERFORMANCE OF THIS HEATER, PLEASE CALL OUR
TECHNICAL SERVICE DEPARTMENT TOLL FREE : 1-800-543-6163.
HAVE THE INFORMATION LISTED BELOW WHEN CALLING :
S/N __________ MODEL # _____________________INSTALL DATE__________
EEMAX
ProAdvantage Series
ELECTRIC INSTANTANEOUS WATER HEATER
PA
240 - *
PA
277 - *
1Φ 240V - Series 2
1Φ 277V - Series 2
WARNING
1
Advertisement
Table of Contents
Related Manuals for EemaX PA014240
Summary of Contents for EemaX PA014240
- Page 1 EEMAX ProAdvantage Series ELECTRIC INSTANTANEOUS WATER HEATER INSTALLATION GUIDE AND OWNER’S MANUAL 240 - * 1Φ 240V - Series 2 MODELS COVERED: 277 - * 1Φ 277V - Series 2 WARNING READ THE GENERAL SAFETY SECTION AND THE ENTIRE MANUAL BEFORE INSTALLING OR OPERATING THIS WATER HEATER.
-
Page 2: General Safety
GENERAL SAFETY The “Eemax ProAdvantage” heater is specifically designed to take in cold or hot water and heat it up to a maximum of 140F (60C). To obtain optimum performance and energy savings, the unit should be located as near as possible to the point of use. -
Page 3: Mounting The Unit
If local codes require the use of a temperature and pressure relief valve it should be installed on the outlet hot water pipe before the outlet ball valve. Lavatory Shower MODELS: Kitchen 240 - * 1Φ 240V - Series 2 277 - * 1Φ 277V - Series 2 Eemax Hot outlet Cold inlet... - Page 4 Mounting Layout for Series 2 Systems Figure 1...
-
Page 5: Plumbing Hook-Up
II. PLUMBING HOOK-UP 1) The unit is supplied with ¾’’ NPT fittings (Fig. 2a), USE THESE. DO NOT USE PIPE DOPE AND DO NOT SOLDER TO THE INLET OR OUTLET. 2) Take care to ensure that the pipes are correctly aligned with the inlet and outlet bosses in order to avoid excessive stress on the heater body molding. - Page 6 MINIMUM - 8” CLEARANCE ABOVE UNIT Figure 2b GROUND PEM STUD Pipe support Elbow To Two Dedicated Independent circuit Pipe support breakers. If applicable - UL499 18.4, 150% of the Union products’ current rating. Threaded type Outlet Isolating Teflon tape only Ball Valve No pipe dope (throttle open...
-
Page 7: Electrical Hook-Up
WARNING BEFORE DOING ANY WORK ON THE UNIT BE SURE BOTH BREAKERS ARE “OFF” TO AVOID ANY DANGER OF SHOCK. “Eemax Home Advantage” heaters are manufactured to the following specifications: Table 1 M O DE L TY P E V oltage... - Page 8 IV COMMISSIONING YOUR HEATER IMPORTANT BEFORE SWITCHING “ON” THE POWER AT THE MAIN CIRCUIT BREAKER PANEL MAKE SURE THAT THE HOT WATER CIRCUIT IS FREE OF AIR POCKETS OR ELSE PREMATURE FAILURE OF THE ELEMENT WILL OCCUR. TO DO THIS OPEN ALL HOT WATER OUTLETS ONE AT A TIME FOR A MINUTE OR TWO UNTIL THE WATER FLOW IS CONTINUOUS AND FREE FROM “GULPING”...
-
Page 9: Troubleshooting
The resistance reading should be roughly 5.0 ohms. If the resistance is much greater than this value, call Eemax for a replacement element. 5) ECO TRIPPED (High Limit Thermostat) TURN OFF THE TWO MAIN CIRCUIT BREAKERS! Reset by pushing in red button on each heater module. - Page 10 EX1049-1 TRIAC EX278C EX1050-1...
