Blaupunkt WAS100 Instruction Manual

WAS100
MP3 & FM RECEIVER
Instruction Manual
1 6 2 17 16 13
BLAUPUNKT
FM/USB/SD MP3 PLAYER
5
21
3
WASHINGTON 100
1 8
19 20 4 7 8 9 10 11 12
RECEIVER CONTROLS
1. Power ON/OFF
2. Mode : Radio, USB, SD, AUX in
3. Auto Seek Search Tuning AMS
4. Band Button FM1, FM2, FM3
5/6. Track Skip/ Search Forward/ Backward, Browse Radio Station
7. Preset Station 1~ 6 for Radio and Play/ pause Function for MP3/WMA
8. Intro Function for MP3/WMA
9. Repeat Function for MP3/WMA
10. Random Playback Funtion for MP3/WMA
11. Go back 10 for Long List and Menus in SD/ USB Mode
12. Skip Ahead 10 for Long List and Menus in SD/ USB Mode
13. SD Card Slot
14. Aux In Port
15. USB Port
16. LCD Display
17. Volume/ Select Control
18. Mute Button
19. EQ Button
20. Clk Botton
Please read this instruction manual carefully and familiarize yourself with
your new Stereo Reciever before using it for the rst time. Please keep this
manual for future reference.
15
FEATURES
The Unit Features FM Stereo with USB & SD/MMC Ports and:
Electronic PII Tuning Control With 18 Programmable Stations
MP3/WMA Compatible
14
Preampli ed Line-out
From Audio Aux-in
USB Port and SD/MMC Input
Last Track Memory ( Radio & SD/ MMC & USB)
KEY FUNCTIONS
1. POWER ON/OFF
Press shortly to turn ON. Press for three seconds to turn the unit OFF.
2. MODE-FUNCTION SELECTOR
Press to cycle through di erent playblack modes in the following
sequence: RADIO/ USB/ SD/AUX IN.
3. AUTO SEEK SEARCH TUNNING (AMS)
In radio mode press to seek radio station automatically, press and hold to
automatically save the station.
4. BAND BUTTON
In radio mode press to cycle through di erent FM bands. (FM1-FM2-FM3)
5/6. BUTTON
In MP3/USB/ SD/ MMC Mode press to go to desired track.
In Radio mode press to go to the desired station.
7. 1/ BUTTOM
In Radio mode press to go to preset station #1. In USB/ SD/ MMC mode to
press to start music playback.
During playback press again to pause playback. Press again to resume play.
8. 2/INT BUTTON
Pressing this key will playback a snippet of each thack. Press again to stop
snippet and listen to the full track. While this mode is actived "INT" will be
displayed.
In Radio mode press to play preset station #2.
9. 3/ RPT BUTTON
Press this key will activate Repeat mode. They current track will be
continually repeated until repeat is deactivated. When this mode is
activated RPT will appear.
In Radio mode press to play preset station #3
10. 4/RDM BUTTON
Pressing this key will activate Random playback mode. When this mode
is activated RDM will appear.
In Radio mode press to play preset station #4
11. 5/-10 BUTTON
In playback mode, short press to -10, long press to choose a folder.
12. 6/+10 BUTTON
In playback mode, short press to +10, long press to choose a folder.
13. SD CARD SLOT
Insert the SD/MMC card is the slot. Select SD with the mode selector.
Audio will begin playback aomatically.
14. AUX IN PORT
Connect your external device to the AUX Port via an auxiliary cable.
Audio will now be played through the car speakers.
15 USB PORT
Connect your external device via USB (not included) to playback audio
if an AUX port is not available.
16. LCD DISPLAY
The LCD Display will show relevant information about the current funtion
that is being performed.
17. VOLUME / SELECT CONTROL
Rotating the volume knob will control the volume. You can also select
funtions by scrolling to them using the volume knob and pressing down.
Pressing down will also give you options to change BASS, TREBLE,
BALANCE, FEDER, LOUD and EQ settings.
18. MUTE BUTTON
Push the mute button to mute all audio.
19. EQ BUTTON
EQ: FLAT/ POP/ CLASS/ ROCK
20. CLK BUTTON
Press to change clock setting.
