B&C Speakers Coaxials 12CXT Specifications

12CXT
Coaxials
400 W continuous program power capacity
XO-2 dedicated crossover network
90° nominal coverage
50 – 20000 Hz response
98 dB sensitivity

Specifications

Nominal Diameter 320 mm (12 in)
Nominal Impedance
Minimum Impedance
7.3 ohm (HF)
Frequency Range 50 - 20000 Hz
Dispersion Angle (1)
LF Unit
Sensitivity (1W/1m) (2)
Nominal Power Handling (3)
Continuous Power Handling (4)
Voice Coil Diameter
Winding Material
HF Unit
Sensitivity (1W/1m) (5)
Nominal Power Handling (6)
Continuous Power Handling (7)
Voice Coil Diameter 36 mm (1.4 in)
Winding Material
Diaphragm Material
Recom. Crossover (8)
Parameters
Fs
Re
Qes
Qms
Qts
Vas 91 dm3 (3.2 ft3)
Sd 522 cm2 (80.9 in2)
Eta Zero
Xmax
Xvar
Mms
Bl
Le
Mounting and Shipping Info
Overall Diameter 316 mm (12.4 in)
Bolt Circle Diameter 296 mm (11.6 in)
Baffle Cutout Diameter 284 mm (11.2 in)
Depth 179 mm (7.05 in)
Flange and Gasket Thickness 13 mm (0.5 in)
Net Weight 5.6 kg (12.3 lb)
Shipping Weight 6.8 kg (15 lb)
Shipping Box 380x380x240 mm
(15.2x15x9.4 in)
8 ohm
6 ohm (LF)
90°
98 dB
200 W
400 W
51 mm (2 in)
Copper
102 dB
25 W
50 W
Aluminium
Mylar
2.2 kHz
49 Hz
5.3 ohm
0.35
3.9
0.32
3.1 %
+/- 3 mm
+/- 5.5 mm
43 g
14.4 Txm
1.2 mH
