B&C Speakers 12PLB76 Specification

12PLB76
Woofer
700 W continuous program power capacity
76 mm (3 in) aluminium voice coil
50 – 2000 Hz response
98.5 dB sensitivity
Specification
Nominal Diameter 320 (12) mm (in)
Nominal Impedance (1)
Minimum Impedence
Nominal Power Handling (2)
Continuous Power Handling (3)
Sensitivity (1W/1m) (4)
Frequency Range 50 - 2000 Hz
Voice Coil Diameter 76 (3) mm (in)
Winding Material
Former Material
Winding Depth 16 (5/8) mm (in)
Magnetic Gap Depth 10.5 (0.4) mm (in)
Flux Density
Thiele & Small Parameters
Fs
Re
Qes
Qms
Qts
Vas 75 (2.6) dm3 (ft3)
Sd 522 (80.9) cm2 (in2)
Eta Zero
Xmax
Xvar
Mms
Bl
Le
Mounting and Shipping Info
Overall Diameter 316 mm (12.4 in)
Bolt Circle Diameter 296 mm (11.6 in)
Baffle Cutout Diameter 282 mm (11.1 in)
Depth 136 mm (5.35 in)
Flange and Gasket Thickness 16 mm (5/8 in)
Net Weight 7.4 kg (16.4 lb)
Shipping Weight 8.2 kg (18 lb)
Shipping Box 340x340x170 mm
(13.4x13.4x6.7 in)
1 For different impedances, please ask.
2 2 hours test made with continuous pink noise signal (6 dB crest factor).
Power calculated on rated minimum impedance.
3 Power on Continuous Program is defined as 3 dB greater than the
Nominal rating.
4 Applied RMS Voltage is set to 2.83V for 8 ohms or 2.0V for 4 ohms
Nominal Impedance
8 Ohm
6.4 Ohm
350 W
700 W
98.5 dB
Aluminium
Glass Fibre
1.05 T
50 Hz
5.3 Ohm
0.24
5.2
0.23
3.8 %
+/- 5 mm
+/- 7 mm
51 g
18.6 Txm
1.2 mH
