B&C Speakers Mid-Bass 10MD26 Specification

10MD26
Mid-Bass
700 W continuous program power capacity
76 mm (3 in) aluminium voice coil
80 – 4000 Hz response
100 dB sensitivity
Specification
Nominal Diameter 250 (10) mm (in)
Nominal Impedance (1)
Minimum Impedence
Nominal Power Handling (2)
Continuous Power Handling (3)
Sensitivity (1W/1m) (4)
Frequency Range 80 - 4000 Hz
Voice Coil Diameter 76 (3) mm (in)
Winding Material
Former Material
Winding Depth 11(7/16) mm (in)
Magnetic Gap Depth 8 (5/16) mm (in)
Flux Density
Thiele & Small Parameters
Fs
Re
Qes
Qms
Qts
Vas 20 (0.71) dm3 (ft3)
Sd 320 (49.1) cm2 (in2)
Eta Zero
Xmax
Xvar
Mms
Bl
Le
Mounting and Shipping Info
Overall Diameter 262 mm (10.3 in)
Bolt Circle Diameter 245 mm (9.6 in)
Baffle Cutout Diameter 230 mm (8.8 in)
Depth 124 mm (4.9 in)
Flange and Gasket Thickness 14 mm (0.55 in)
Net Weight 7.3 kg (16.1 lb)
Shipping Weight 7.9 kg (7.4 lb)
Shipping Box 320x320x160 mm
(12x12x6.3 in)
1 For different impedances, please ask.
2 2 hours test made with continuous pink noise signal (6 dB crest factor).
Power calculated on rated minimum impedance.
3 Power on Continuous Program is defined as 3 dB greater than the
Nominal rating.
4 Applied RMS Voltage is set to 2.83V for 8 ohms or 2.0V for 4 ohms
Nominal Impedance
8 Ohm
7.2 Ohm
350 W
700 W
100 dB
Aluminium
Glass Fibre
1.45 T
76 Hz
5.8 Ohm
0.22
4.8
0.21
3.9 %
+/- 1.5 mm
+/- 4.5 mm
31 g
19.6 Txm
1.2 mH
