To:
All Service Managers
Cc:
Warranty Administrators, Technicians
From:
Peter Tolley
Subject: Hyundai Audio Fitment and Aftermarket Servicing & Claim
Procedure
We have attached the installation procedure for Hyundai Audio Systems. Refer
to the respective procedures for each vehicle from the page numbers referred
to in table one. The table below provides details of the first VIN No's when we
commenced installing Hyundai Audio System.
The second table provides details of which Audio units are installed into which
vehicle.
The third table provides a list of the individual parts and their part number.
Please read page three of the bulletin and familiarise yourselves with the
Hyundai Warranty Replacement Procedures. If you follow these instructions the
process will be easily managed. If you do experience any difficulties please
contact our office for advice.
Table One
VEHICLE MODEL
SM Santa Fe
TB Getz
FC Lavita
GK Tiburon
LC Accent
XD Elantra
EF Sonata
HP Terracan
FO Trajet
H100 Van/Truck
XG30
Service Bulletin
VIN NUMBER
KMHSC81DR3U347234
KMHBT31HR3U002640
KMHPM81CR3U068611
KMHHN61FR3U053428
KHMCG51BR2U173685
KMHDM51CR3U074608
KMHEN41FR3A724340
KMHNM81CR3U066410
KHMMH81CR3U142326
1
th
18
September 02
02031
PAGES
4 ~ 8
9 ~ 14
15 ~ 20
21 ~ 26
27 ~ 34
35 ~ 41
42 ~ 47
48 ~ 53
54 ~ 60
Sony Fitted Stereo
Factory Fitted Stereo
