A. Handlebar Cover
B. Handlebar Adjuster
C. Right Folding Button
D. Left Folding Button
E. Seat Unit
F. Seat Disassembly Button
G. Joint Point Cover
H. Brake Bar
Please Note: The Carrycot/Seat Unit Frame (R) and the Carrycot Fabric are already assembled
as component (S). When converting from carrycot mode to stroller mode, the carrycot fabric
will need to be removed from the carrycot frame in order for the seat unit to be assembled as
component (T).
03

Components

I. Storage Basket
J. Rear Wheel
K. Wheel Disassembly Button
L. Canopy
M. Bumper Bar
N. Canopy Connector
O. Recline Buttons
P. Revolving Lock
Q. Front Wheel
L
M
N
O
P
Q
R. Seat/Carrycot Frame
S. Carrycot Fabric
T. Seat Unit Fabric
U. Chassis
V. Carrycot Apron
W. Foot Warmer
X. Seat Liner
Y. Raincover
