LevelOne PIS-3100 User Manual

Check your package contents

The carton should contain the following items:
PSE Device
PD Device
Power Cords
If any item is found missing or damaged, please contact your local reseller for replacement.

General Feature

PSE

Power Sourcing Equipment (PSE) transforms AC to DC. It has a maximum output power of 30W,
fluctuation of 30mV with a tolerance of ±3%. When it overflows, overloads, short-circuits, or overheats,
the PSE automatically turns off the power, and restarts after these problems are removed.
When PSE detects that it connects to a device which uses no electricity, the power supply will be turned
off automatically.
PSE monitors circuit status at all times. Once it detects that it connects to an electronic device that has a
range between 1-30W, it automatically provides electricity to it. When it is lower than 1W electricity will
not be supplied.
PSE protects circuits from problems such as short-circuit, overload, and electricity receiving device
damage by turning off the power once a problem occurs. Normal power supply will be resumed once
these problems are eliminated

Connector

Data and power out: 1 x RJ-45.
- Data pin 1,2,3,6
- Power pin: 4,5(V+), 7,8(V-)

PD

Turns any device into a PoE-capable device
Compatible with Access Points, Network Cameras, or other DC 12V devices(up to 24W)
Connector
Data and power in: 1 x RJ-45
- Data pin 1,2,3,6
- Power in: 4,5(V+), 7,8(V-)
Data out: 1 x RJ-45
- Data pin 1,2,3,6
Power out: 12V/2A
PIS-3100 High Power PoE Adapter Combo Kit
User's Manual
