Trojan 6V-GEL Quick Start User Manual

INSULATED WRENCH BATTERY CHARGER
BAKING SODA VENTILATION
(Sodium Bicarbonate)

BATTERY CONNECTION

†
If using washers to connect the wire connections, ensure the
■
connection is in direct contact with the lead surface of the terminal.
Ensure the washer is placed on top of the wire connection (between
■
the connection and the nut).
Do not place the washer between the terminal and the connection
■
as this creates high resistance and can cause terminal meltdown.
*
Nut
Cable Lug
Washer*
Terminal
Bolt
†
Hardware not supplied by Trojan
TORQUE VALUES
Tighten all cable connections to the specified values* , ensuring
■
proper contact with the terminals. Over-tightening can result in
terminal breakage and loose connections, which may result in
meltdown or fire.
* Consult comprehensive User's Guide on www.trojanbattery.com/
literature/#usersguide for detailed information.

TERMINAL PROTECTION

Keep terminals clean and dry to avoid corrosion. Terminal protector
■
spray is recommended.
2
Trojan Battery Company
Over 200 Years of combined engineering
■
expertise
Full range of advanced Deep-Cycle Flooded,
■
AGM and Gel batteries
Quality components for reliability and
■
performance
Industry-Leading Return on Investment and
■
Low Cost of Ownership
Outstanding technical and customer service
■
Made in USA since 1925
■
Trojan's battery testing
■
procedures adhere to both
BCI and IEC test standards.
Global - Sold in over 120 countries
■
Learn more at
www.trojanbattery.com
Your Local Trojan Battery Representative:
©2016 TROJAN BATTERY COMPANY, LLC. ALL RIGHTS RESERVED. TROJAN BATTERY COMPANY
IS NOT LIABLE FOR DAMAGES THAT MAY RESULT FROM ANY INFORMATION PROVIDED IN
OR OMITTED FROM THIS PUBLICATION, UNDER ANY CIRCUMSTANCES. TROJAN BATTERY
COMPANY RESERVES THE RIGHT TO MAKE ADJUSTMENTS TO THIS PUBLICATION AT ANY TIME,
WITHOUT NOTICE OR OBLIGATION.
TRJN0247_QSG_GEL_0516
GEL BATTERY
QUICK START USER'S GUIDE
Battery Installation & Maintenance
BATTERY INSTALLATION

MAINTENANCE and INSTALLATION EQUIPMENT NEEDED

GOGGLES PROTECTIVE CLOTHING
GLOVES DISTILLED OR TREATED WATER
(only for terminal cleaning)

SAFETY

Always wear protective clothing, gloves and goggles.
■
Do not smoke near batteries.
■
Keep sparks, flames and metal objects away from batteries.
■
Use insulated tools when making battery connections.
■
Electrolyte is a solution of acid and water, so avoid skin contact. If
■
acid contacts skin or eyes, flush with water immediately and contact
a medical professional.
Ensure the cable connections to the terminals are properly
■
tightened.
Do not lay objects on top of battery.
■
Always charge and handle batteries in a well-ventilated area.
■
Never add acid to a battery.
■
Never remove or alter gel vent caps.
■

BATTERY ORIENTATION

Unlike flooded batteries, gel batteries may be placed and
■
installed upright or on their sides.
1
