HL‑L8260CDN / HL‑L8260CDW / HL‑L8360CDW /
HL‑L9310CDW
Quick Setup Guide
Unpack the machine and check the components
Watch our Video FAQs for
help with setting up your
(Black, Cyan, Magenta and Yellow)
Brother machine:
solutions.brother.com/videos.
1
Remove the packing materials and install the drum unit and toner cartridge assembly
Remove the packing tape.
1
2
2

Load paper in the paper tray

3
Connect the power cord and turn the machine on
Back
4
Select your language (if needed)
„ For LCD models
1.
Press ▼ or ▲ to select [Initial Setup], and
then press OK.
2.
Press OK to select [Local Language].
3.
Press ▼ or ▲ to select your language, and then
press OK.
4.
Press Cancel.
Drum Unit*
Waste Toner Box*
Inbox Toner Cartridges*
Brother Installation Disc
Quick Setup Guide
Product Safety Guide
3
4
Front
Read the Product Safety Guide first, then read this Quick
Setup Guide for the correct installation procedure.
Not all models are available in all countries.
The latest manuals are available at the Brother Solutions
Center: solutions.brother.com/manuals.
NOTE:
* Already installed in the machine
• The components included in the box may differ depending on your
• The available connection interfaces vary depending on the model.
• Interface cables are not included. If you require one, it will need to be
Belt Unit*
• The illustrations in this Quick Setup Guide show the HL-L8360CDW.
AC Power Cord
Reference Guide
(only for certain models)
Do not exceed this mark.
Adjust the paper
guides.
„ For Touchscreen models
1.
On the machine's Touchscreen, press
[Settings] > [All Settings] >
[Initial Setup] > [Local Language].
2.
Press your language.
3.
Press
.
country.
purchased. Use one of the following cables:
USB cable
We recommend using a USB 2.0 cable (Type A/B) that is no
more than 2 metres long.
Network cable
Use a straight-through Category 5e (or greater) twisted-pair
cable.
D00EPH001-00
UK
Version 0
