tower unit shelves only
(400 & 600mm wide)
Assembly Instructions
CONTENTS:
A
1x Top panel
B
1x Side panel (left)
C
1x Side panel (right)
D
6x Shelves
E
1x Plinth panel
RECOMMENDED:
• TOOLS:
Screwdriver
• TWO PERSON BUILD
Page 1 of 4
2x
32x
32x
Wall mounting
Cams
Dowels
brackets
We recommend you use the Wall Mounting
Brackets provided to fix the Tower Unit to a
wall (where possible). This will prevent the
unit being pulled over. Use suitable fixings.
www.spacepro.co.uk/instructions-2/
V1
SPR_INSTRUC_TU_DR_05.2016
Advertisement
Table of Contents
Related Manuals for Spacepro Tower unit shelves
Summary of Contents for Spacepro Tower unit shelves
- Page 1 (400 & 600mm wide) Assembly Instructions CONTENTS: 1x Top panel 1x Side panel (left) 1x Side panel (right) 6x Shelves Wall mounting Cams Dowels brackets 1x Plinth panel RECOMMENDED: We recommend you use the Wall Mounting •...
- Page 2 Note: B panel shown Lay panels (B &C) on a flat surface. Fit cams & dowels to both panels. Apply to all panels. Page 2 of 4 www.spacepro.co.uk/instructions-2/ SPR_INSTRUC_TU_DR_05.2016...
- Page 3 Ensure cams are facing inwards. Page 3 of 4 www.spacepro.co.uk/instructions-2/ SPR_INSTRUC_TU_DR_05.2016...
- Page 4 Use suitable fixings. Fix the Wall Mounting Bracket to both sides of the Tower Unit. (Use suitable fixings when attaching to the wall). Use two people to stand up straight. Page 4 of 4 www.spacepro.co.uk/instructions-2/ SPR_INSTRUC_TU_DR_05.2016...
