SUSPA GmbH
Translation of the
original operating instruction
English
Electrically adjustable table base frame
Type ELS3
Read the operating instructions prior to the first commissioning.
Follow the safety instructions.
Please retain for future use! Get the current operating instructions
at
www.suspa.com/uk/suspa-service0/downloads/user-manuals/
July 2014
Advertisement
Table of Contents
Related Manuals for Suspa ELS3
Summary of Contents for Suspa ELS3
- Page 1 SUSPA GmbH Translation of the original operating instruction English Electrically adjustable table base frame Type ELS3 Read the operating instructions prior to the first commissioning. Follow the safety instructions. Please retain for future use! Get the current operating instructions www.suspa.com/uk/suspa-service0/downloads/user-manuals/...
- Page 2 At delivery SUSPA GmbH will replace or repair defective products covered by the warranty;...
- Page 3 Other symbols and tags Symbol Explanation Handling instructions Provides instructions for a specific action. Note Important information for understanding the device or for optimized operations. Table base frame ELS3...
- Page 4 Warning signs Symbol Explanation Symbol Explanation Warning - Danger zone Warning – Hazardous electrical voltage Warning - Risk of hand injuries Warning - Trip hazard Mandatory signs Symbol Explanation Symbol Explanation Observe information provided Observe additional information Table base frame ELS3...
-
Page 5: Table Of Contents
Additional information Installation ............................... 11 Scope of supply View after assembly Operating conditions Dimensions and technical data 4.4.1 Lifting column ELS3 BTU 4.4.2 Lifting column ELS3 BTD 4.4.3 Dimensions SUSPA COMPACT controller 4.4.4 Dimensions SUSPA SMART controller Setup and installation 4.5.1... - Page 6 5.2.1 HSM-OD-2-LD up-down manual switch 5.2.2 Perform a reset Decommissioning............................25 Switch off adjustment function Storing the table base frame Disposal of table base frame Spare parts ............................... 25 Original EC Declaration of Conformity ........................26 Table base frame ELS3...
-
Page 7: Identification
Other use of the electrically adjustable table base frame or use beyond its intended purpose is considered non-intended and thus improper. In this case, the safety may be impaired or compromised. SUSPA GmbH assumes no liability for damage resulting from such improper use. Intended use also includes: ... -
Page 8: General Instructions
General Instructions Warranty and Liability In principle the “General Terms of Sale and Delivery” of SUSPA GmbH apply. These can be accessed online at www.suspa.com under Downloads/”General Terms and Conditions”. Liability and warranty claims in the case of damage to persons or objects are excluded if they can be attributed to one or more of the following causes: ... -
Page 9: General Safety Instructions
The ELS3 table base frame has been constructed according to state-of-the-art technology and recognized safety regulations. In order to prevent danger to life and limb of the user, third parties, or to the table base frame, use the ELS3 only for its intended purpose and in perfect condition with regard to safety. -
Page 10: Dangers From Mechanical Energy
Residual electrical energy remains in lines, controller, and motor after the table base frame is shut down. In order to install and repair the table base frame, it must be disconnected from the mains. Regularly check the electrical cabling of the table base frame. Replace damaged cables. Table base frame ELS3... -
Page 11: Additional Information
other applicable regulations Installation Follow safety chapter Observe and follow the Chapter “General safety instructions” from page 9. Check the delivery for completeness, damage or anything else that is conspicuous! Table base frame ELS3... -
Page 12: Scope Of Supply
Check that the supplied and delivered lifting column system is complete! These operating instructions apply for the following types: Electrical lifting column system ELS3, BTU (slender tube at bottom) Electrical lifting column system ELS3, BTD (slender tube at top) - Page 13 Part No.: 098 10011 098 10011 Quantity: 1 Quantity: 1 The following table base frame is designed for assembly with the electric lifting column system ELS3 BTU or the electric lifting column system ELS3 BTD. Table base frame Explanation Components...
-
Page 14: View After Assembly
Operating conditions Physical operating conditions Operating site Office Operating temperature +15 °C to +30 °C Air humidity 30 % to 60 % Ambient conditions No heavy dirt or contamination caused by dust, acids and corrosive gases Table base frame ELS3... -
Page 15: Dimensions And Technical Data
Dimensions and technical data 4.4.1 Lifting column ELS3 BTU 202 mm Lifting column view from the top 1220 mm 570 mm Technical data – ELS3 lifting column Dimensions: Lifting column 60/65/70 mm Lift 650 mm Retracted height 570 mm Extended height... -
Page 16: Lifting Column Els3 Btd
4.4.2 Lifting column ELS3 BTD 202 mm Lifting column view from the top 1220 mm 570 mm Technical data – ELS3 lifting column Dimensions: Lifting column 70/65/60 mm Lift 650 mm Retracted height 570 mm Extended height 1220 mm Weight 7.5 kg... -
Page 17: Dimensions Suspa Compact Controller
4.4.3 Dimensions SUSPA COMPACT controller Technical Data – SUSPA COMPACT controller Output performance 280 VA Standby consumption < 0.3 W Weight approx. 420 g Dimensions 264 x 103 x 37 mm Input voltage 207-253 V / 50 Hz Ambient temperature, 0-30 °C... -
Page 18: Setup And Installation
Setup and installation When assembling the table base frame ELS3 for office tables or desks with a custom table top into a finished table, the following points must be observed (see drawing below): The table base frame is suitable for table top sizes of max. 800 mm deep and 1200 mm – 1900 mm in length. -
Page 19: Step 1 Install Table Base Frame
places with screw B to the transverse web inserts for lifting columns. Fasten the lifting columns in 4 places with screw C to the longitudinal joints of the table top. B screws C screws Table base frame ELS3... -
Page 20: Step 2 Fasten The Table Base Frame To The Table Top
Observe the maximum torque of 10 Nm of the A screws. Each of the foot tubes has a base plate with 4 mounting holes. Screw the foot sections onto the feet tubes of the lifting columns with 4 A screws each. Table base frame ELS3... -
Page 21: Step 4 Fasten Controller To The Table Top
Do not bend the cable! Do not place heavy objects on the cable! Do not pull on the cable! Pull the mains plug to disconnect the table base frame from the power supply! Table base frame ELS3... - Page 22 Make sure that there are no people, animals or objects in the entire travel path of the lifting columns! Connect the motor cable of a lifting column with input M1 of the controller. Connect the motor cable of the second lifting column with input M2 of the controller. Table base frame ELS3...
- Page 23 the controller. At least two people are needed to place the fully assembled table on its feet. If necessary, level the table using the adjustable feet. Perform a reset, see page 24. Table base frame ELS3...
-
Page 24: Commissioning / Operation
5-20 seconds) the lifting columns have moved down to the lowest position followed by an upward movement of approx. 2-3 mm. CAUTION Perform a reset after every disassembly or exchange of the lifting columns and/or controller. Table base frame ELS3... -
Page 25: Decommissioning
Due to the danger of possible environmental pollution, have the table base frame disposed of by an approved specialized company! Spare parts Use only spare parts from the manufacturer of the table base frame, SUSPA GmbH. For ordering spare parts, contact the following address: ... -
Page 26: Original Ec Declaration Of Conformity
This declaration will lose its validity if any modifications are made to the machine without consultation with us. Any unauthorized modifications in this sense excludes any liability on our part. Name / Signature (Management SUSPA GmbH) Table base frame ELS3...
