SUSPA GmbH
Assembly Instructions
English
Table Frame
Type VariFrame
The assembly instructions must be read carefully prior to initial
commissioning!
Follow the safety instructions!
This table frame is intended to be incorporated into machinery, partly
completed machinery/equipment or to be joined with another framework
so as to form a complete machine as specified under the Machinery
Directive. The machine should be put into operation only after a conformity
evaluation procedure in accordance with the Machinery Directive has been
carried out for the complete machine.
No revision service applies to this documentation. The updated assembly
instructions are available at
http://www.suspa.com/de/service/downloads/
Advertisement
Table of Contents
Related Manuals for Suspa VariFrame
Summary of Contents for Suspa VariFrame
- Page 1 SUSPA GmbH Assembly Instructions English Table Frame Type VariFrame The assembly instructions must be read carefully prior to initial commissioning! Follow the safety instructions! This table frame is intended to be incorporated into machinery, partly completed machinery/equipment or to be joined with another framework so as to form a complete machine as specified under the Machinery Directive.
- Page 2 90518 Altdorf GERMANY or its legal successor. The contents of the user information is the intellectual property of SUSPA GmbH. SUSPA GmbH expressly reserves the ownership of and copyright to the data contained in the user information. Reproduction and duplication, even in excerpts, are permitted only upon the written consent of SUSPA GmbH.
-
Page 3: Table Of Contents
Screw connection of the cross beam – Tabletop size: 1400 to 2000 x 800 mm ....26 5.3.2.7 Screw connection of the table base frame to the tabletop ............ 27 5.3.2.8 Installation of the foot base and adjustable glides ..............28 VariFrame – Assembly Instructions page 3... - Page 4 Overloading the table frame ......................36 6.3.2 Damages to electrical wires ....................... 36 Decommissioning ......................37 Component storage ..........................37 Disposal of components ........................37 Appendix ..........................38 Index of Tables ............................38 Index of Figures ............................. 39 VariFrame – Assembly Instructions page 4...
-
Page 5: Information Concerning This Document
IMPORTANT Note excludes the danger of damage to property and the risk of injuries. Draws attention to specific safety- SAFETY INSTRUCTION Safety instruction relevant instructions or procedures. Table 1 Signal words and signal colors VariFrame – Assembly Instructions page 5... -
Page 6: Symbols
Note understanding the device or for optimized operations. Table 2 Symbols 1.3.1 Warning notice Symbol Explanation Symbol Explanation Warning against General warning sign hazardous electrical voltage Warning of hand injuries Table 3 Warning notice VariFrame – Assembly Instructions page 6... -
Page 7: Identification And Notes
This partly completed machinery is intended to be incorporated into other machinery, other partly completed machinery/equipment or to be joined with another framework so as to form a complete machine as specified under the Machinery Directive. The machine should be put into operation only VariFrame – Assembly Instructions page 7... -
Page 8: Reasonably Foreseeable Misuse
installation of the table frame on components that have not been approved by SUSPA GmbH for this system Using components for the operation of the table frame, in this case the electrical ... -
Page 9: General Instructions
2.5 General instructions 2.5.1 Warranty and liability The "General Terms and Conditions" of SUSPA GmbH always apply. They have been made available to the owner since the contract was signed at the latest. Warranty claims and liability claims for personal injury and material damage are excluded if they are attributed to one or more of the following causes: ... -
Page 10: Target Group Of The Assembly Instructions
Private person Persons who have no previous knowledge in the installation of mechanical and electrical components. Outside the Federal Republic of Germany, the accident prevention regulations and safety provisions of the respective country apply. VariFrame – Assembly Instructions page 10... -
Page 11: Safety Instructions
Heed all the warnings and safety notices in these assembly instructions. The following circumstances could increase the hazard potential of the components: Hazard posed to persons through mechanical influences Malfunctions that may impair the safety during operation of the component VariFrame – Assembly Instructions page 11... -
Page 12: Responsibilities Of The Operating Company
Applicable and binding accident-prevention regulations Applicable and binding regulations at the place of use Recognized technical regulations for safe and professional working methods Existing environmental protection regulations Other applicable regulations VariFrame – Assembly Instructions page 12... -
Page 13: Design And Function
M10 x 20 mm, diameter 63 mm Table 5 Technical specifications IMPORTANT The dimensions of the tabletop must not protrude over the installed frame by more than 100 mm on the longitudinal side and 130 mm on the narrow side. VariFrame – Assembly Instructions page 13... -
Page 14: Design And Function Of The Table Frame
The individual components and the assembly of the table frame are described in the following. Figure 1 Arrangement of the VariFrame table frame components Figure 2 VariFrame cross beam (length = 1128 mm) – pos. A VariFrame – Assembly Instructions... - Page 15 Figure 4 Foot base-Q (length = 750 mm) – pos. C Figure 5 Foot base-RE (length = 750 mm) – pos. D Figure 6 M6 x 10 mm raised head screw – pos. E VariFrame – Assembly Instructions page 15...
-
Page 16: Packaging Units And Weights
16 kg here. IMPORTANT When handling the packaging units, observe the respective weights of type VariFrame tabletops. In particular, adhere to applicable regulations, provisions and laws regarding the lifting and carrying of loads. VariFrame – Assembly Instructions... -
Page 17: Installation
Check all components for any damage that may have occurred during transport or installation before operating the system. Do not try to dismantle the system or system components. Contact SUSPA GmbH in the event that components must be repaired or replaced. 5.1 Unpacking Proceed with the necessary diligence and caution when unpacking the system components. -
Page 18: Operating Conditions
Installation Scope of delivery example: VariFrame table frame for square lifting columns in RAL 9006: 4 x cross beams 1128 mm in RAL 9006 2 x fixing plates in RAL 9006 2 x foot bases-Q in RAL 9006 ... -
Page 19: Installation Of Components
When laying cables, make sure that the cable is not crushed or stretched. Position the power cord to prevent tripping hazards. Use only accessories authorized and provided by SUSPA. First check whether the individual components are damaged. If this is the case, do ... -
Page 20: Installation Of The Table Base Frame
Installation 5.3.2 Installation of the table base frame The following requirements must be met for the assembly of the table base frame (VariFrame table frame and ELS3 lifting columns) with a customized tabletop to form a fully assembled table: The table base frame is suitable for tabletops with a depth of 600 mm – 800 mm, see ... -
Page 21: Alignment Of The Lifting Columns
Protect the top surface of the tabletop against scratching by placing cardboard underneath it. Place one lifting column each in the approximate center (referring to the depth of the tabletop) of the bottom surface of the tabletop. Figure 11 Positioning the lifting columns VariFrame – Assembly Instructions page 21... -
Page 22: Positioning The Cross Beams - Tabletop Size: 1200 Mm X 800 Mm
The lifting columns and cross beams must be aligned with each other. The boreholes for the cross beam match the boreholes for the lifting columns. Figure 12 Positioning the cross beam (pos. A) VariFrame – Assembly Instructions page 22... -
Page 23: Positioning The Cross Beams - Tabletop Size: 1400 Mm To 2000 Mm X 800 Mm
The cross beams should overlap as much as possible. In proper position, each pair of cross beams can be screwed together at four places respectively. Figure 13 Positioning the cross beam (pos. A) VariFrame – Assembly Instructions page 23... -
Page 24: Positioning The Fixing Plate
B) to clasp around the cross beams (pos. A) and the lifting column. The elongated holes in the fixing plate match the boreholes for the cross beam and lifting column. Figure 14 Positioning of the fixing plates (pos. B) VariFrame – Assembly Instructions page 24... -
Page 25: Screw Connection Of The Frame Components With The Lifting Columns
The maximum tightening torque for pos. E, M6x10 raised head screw is 7 Nm. Figure 15 Cross beam screw connections Figure 16 Maximum thread depth for the installation of the lifting columns VariFrame – Assembly Instructions page 25... -
Page 26: Screw Connection Of The Cross Beam - Tabletop Size: 1400 To 2000 X 800 Mm
fixing plates (pos. B) to the edge of the table to 30 mm. The maximum tightening torque for each screw connection is 7 Nm maximum. Figure 17 Screwing the cross beams together VariFrame – Assembly Instructions page 26... -
Page 27: Screw Connection Of The Table Base Frame To The Tabletop
Screws that are too long will penetrate the top surface of the tabletop and damage it! IMPORTANT Screws to fasten the table base frame to the tabletop are not included in the scope of delivery. VariFrame – Assembly Instructions page 27... -
Page 28: Installation Of The Foot Base And Adjustable Glides
Ensure that the foot base are aligned parallel to the fixing plate (pos. B). Screw in the adjustable glides (pos. H) by hand into the designated threads on the foot base (pos. C or pos. D). Figure 19 Screw connection of the foot base VariFrame – Assembly Instructions page 28... - Page 29 Observe the maximum torque of 10 Nm for the screws (pos. G)! The foot base must each be fastened with four screw connections between the foot base and the lifting column. The screws are tightened crosswise with the specified torque. VariFrame – Assembly Instructions page 29...
-
Page 30: Installation Of The Electrical Controller (Exemplary)
IMPORTANT The controller must always move with the lifting columns on their travel path! IMPORTANT Screws to fasten the controller to the tabletop are not included in the scope of delivery. VariFrame – Assembly Instructions page 30... -
Page 31: Installation Of The Manual Switch (Exemplary)
IMPORTANT The manual switch must always move with the lifting columns on their travel path! IMPORTANT Screws to fasten the manual switch to the tabletop are not included in the scope of delivery. VariFrame – Assembly Instructions page 31... -
Page 32: Connections And Electrical Lines (Exemplary)
Plug the power connector into the matching input on the electrical controller. IMPORTANT Ensure that only the controller provided with the ELS3 lifting columns is used to operate the table base frame. VariFrame – Assembly Instructions page 32... -
Page 33: Laying Of Electric Wires And Cables (Exemplary)
Check the electrical lines and cables to ensure that they are fastened securely and have not been damaged. 5.4 Space requirements For detailed information on space requirements refer to section 4.1 “Technical specifications“. VariFrame – Assembly Instructions page 33... -
Page 34: Setting Up And Aligning The Table
If necessary, level the table using the adjustable glides. Reset the system. (see https://suspa.com/suspa-downloads/ http://www.logicdata.net/de/download/ Figure 24 Fully assembled table IMPORTANT Ensure that the adjustable glides are not unscrewed too far to protrude from the foot base. VariFrame – Assembly Instructions page 34... -
Page 35: Service And Maintenance
WARNING Risk of sustaining injuries by disregarding the manufacturer’s instructions The function of the components may be impaired as a result of ignoring the manufacturer’s cleaning instructions. Follow all applicable environmental regulations when cleaning. VariFrame – Assembly Instructions page 35... -
Page 36: Maintenance
Drives that repeatedly turn off automatically are an indication that the system is overloaded. 6.3.2 Damages to electrical wires Check the insulation of the electrical wires for visible signs of aging and wear. Replace defective or damaged wiring. VariFrame – Assembly Instructions page 36... -
Page 37: Decommissioning
This includes lubricants, plastics and batteries, etc. Have the machine disposed properly by an authorized specialist company on account of the potential risk of environmental pollution. VariFrame – Assembly Instructions page 37... -
Page 38: Appendix
Table 2 Symbols ..................................6 Table 3 Warning notice ............................... 6 Table 4 Target group ................................10 Table 5 Technical specifications ............................13 Table 6 Operating conditions ............................18 Table 7 Transport and storage conditions ........................37 VariFrame – Assembly Instructions page 38... -
Page 39: Index Of Figures
8.2 Index of Figures Figure 1 Arrangement of the VariFrame table frame components ..............14 Figure 2 VariFrame cross beam (length = 1128 mm) – pos. A ................14 Figure 3 Fixing plate (length = 545 mm) – pos. B ..................... 15 Figure 4 Foot base-Q (length = 750 mm) –...
