Logik L22FE12 Quick Start Manual

22" / 24" Full HD LED TV
Quick Start Guide
Thank you
for purchasing your new Logik TV.
Your new TV incorporates the latest technology to enhance your
viewing experience. We would suggest that you allow about 20
mins for initial setup.
Please follow this guide for a successful first time installation.
GB
1 1
Unpacking
Remove all packaging from the TV. Retain the packaging.
If you dispose of it please do so according to any local
regulations.
TV Screw A x 1
TV Stand Support Screw B x 1
TV Base Instruction Manual
Remote Control / Quick Start Guide
AAA Batteries x 2
3 3
Installing the Base Stand
1. Lay the TV down on a flat surface with the back side facing up. Please make sure a soft cushioned material (such as a pillow or thick piece of foam) is
placed beneath the screen.
2. To install the TV stand, first attach the stand support to the TV by using screw A. Align the screw hole then use screw A to fix the stand support to the TV.
3. To install the base stand, align the screw hole, then secure with a screw driver (not included) using the screw B provided.
Screw A x 1
(P.N.: 209100422B1)
2 2
Operating Your Remote Control
1. Press and lift the back cover to open the
battery compartment of the remote
control.
2. Insert two AAA size batteries. Close the
battery compartment cover.
Make sure the (+) and ( – ) ends
of the batteries match the (+)
and ( – ) ends indicated in the
battery compartment.
screw
TV Front
screw
Base Stand
Front
Screw B x 1
(P.N.: 20912223101)
4 4
Connecting the Aerial
COMMON INTERFACE (CI)
USB HDMI2 HDMI1
HEADPHONE
Connect one end of the RF coaxial cable to the aerial socket on the
L22FE12 wall and the other end of the cable to the RF (75Ω) socket at the rear
right side of your TV.
Do not connect the TV to the mains supply until you
have completed all the connections.
6 6
Turning the TV On for the First Time
The first time you turn the TV on, it will go straight into First Time Installation menu.
First Time Installation
L24FE12 Please ensure aerial is plugged in!
Then press OK button.
Country
UK Belgium Czech France
Australia Bulgaria Denmark Germany
Austria Croatia Finland Greece
OK
7 7
Target Region Descriptor
During tuning your TV may have received signals
from more than one transmitter. If this has occurred
the Target Region Descriptor screen will be
displayed. This will enable you to select the correct
regional transmission for the local news service that
you require.
Press the buttons to adjust each option's setting
and then press the OK button to confirm.
Well done,
your new TV is now ready to use. You will find that there are many exciting features available. To get to know all these
features, please take some time to read the instruction manual provided with your TV.
If after reading the instruction manual you have additional questions related to the use of your TV please call our UK Call Centre on 0844 561 1234.
Our UK Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
5 5
Connecting to the Mains Socket
OR
RF Coxial Cable
(not included)
PC IN RF
PC AUDIO
1. Connect the mains cable to the mains socket after you have
completed all the connections.
2. At this stage, the TV switches to standby mode. The red LED
indicator will illuminate on the front panel of the TV.
3. In standby mode, press the
TV or on the remote control to turn the TV on. The red LED
indicator will turn blue.
1. Press the OK button to
OSD Language
start First Time
Installation menu.
Cesky English Fran ais
Espanol ~
Dansk Hrvatski
Deutsch E k Italiano
OK
3. Press the
Channel Tuning
buttons to select UK as
the country where you
Hungary
will operate the TV.
TV : 3 Channel(s)
Italy
Press the OK button to
DTV : 0 Channel(s)
confirm.
Luxembourg
Radio : 0 Channel(s)
Data : 0 Channel(s)
36%... 668.75MHz
Please press MENU to skip.
This will be shown as GBR for the UK.
This will show the regional country
(e.g. England, Wales, Scotland, NI).
This will allow you to set the region for
your local news service.
You may receive signals from more than
one transmitter within the Secondary
Region, (e.g Beds and Cambs may have
Luton or Sandy Heath).
To mains
socket
button on the right side panel of the
2. Press the buttons
to select English as your
desired language to be
Magyar Polski
displayed on the menu.
Nederlands Portugues
Press the OK button to
Norsk Pycck confirm.
4. Channel tuning will
commence. This operation
may take up to 6 minutes.
The display will show the
progress of the tuning and
the number of channels
found.
(TV)
Target Region Setting
Country Code GBR
Primary Region England
Secondary Region London
Tertiary Region
(P.N.: 4033C226119)
