OUTDOOR USE
KDS-1
ONLY
OWNER'S MANUAL
SAFETY ALERTS, ASSEMBLY & OPERATING INSTRUCTIONS
GENERAL MAINTENANCE & STORAGE
KEEP THIS MANUAL FOR FUTURE REFERENCE
NOT FOR COMMERCIAL USE
This Instruction Manual contains important information necessary for the proper assembly and safe use
of the appliance. You must carefully read and follow all warnings and instructions before assembling
and using the appliance. Follow all warnings and instructions when using the appliance. This manual
is for Barbour International Bayou Classic® products only. If you are using another manufacturer's
product, refer to the manual supplied with that product. Only use approved Bayou Classic®
replacement parts and accessories with this
appliance. For Questions, or to order, please contact:
Barbour International, Inc. • 101 Cypress Way, Brandon, MS 39042
1-800-864-6194 (English Only) • Monday - Friday 7:30am - 4:30pm CST
www.thebayou.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KDS-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Bayou Classic KDS-1

Summary of Contents for Bayou Classic KDS-1

  • Page 1 Follow all warnings and instructions when using the appliance. This manual is for Barbour International Bayou Classic® products only. If you are using another manufacturer’s product, refer to the manual supplied with that product. Only use approved Bayou Classic®...

  • Page 2: Safety Symbols

    SAFETY SYMBOLS CAUTION WARNING DANGER Not following these instructions Hazard or unsafe practices could Hazard or unsafe practices possibly will most certainly result in fire or result in severe property damages, resulting in minor property damages, explosion which will cause property personal injury, or death.
  • Page 3 WARNING • Sober adult operation ONLY! Use of alcohol, prescription or nonprescription drugs may impair ability to properly assemble or safely operate appliance. • Do not use appliance for anything other than its intended purpose. • This appliance is for OUTDOOR USE ONLY, and shall not be used in a building, garage or any other enclosed area.

  • Page 4: Limited Warranty

    Safety Precautions & Warnings Outdoor gas appliance does not have automatic thermostat controls and must be attended and monitored at all times during use. NEVER USE UNDER NEVER LEAVE OUTDOOR USE NEVER USE ON KEEP CHILDREN FLAMMABLE AND PETS AWAY FLAMMABL E UNATTENDED ONLY...

  • Page 5: About This Product

    ABOUT THIS PRODUCT This product is a specialized high pressure gas appliance having greater heat output than traditional kitchen stoves. It can be referred to as a “cooker” or “appliance” in this manual. The appliance is designed to work with a cooking vessel (pot) to steam or boil food. The appliance is only designed to work with an approved hose and regulator utilizing Liquid Propane gas for fuel.

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Read all safety warnings and assembly instructions carefully before assembling or operating your cooker. Inspect contents in the box to ensure all parts are included and undamaged. For missing parts or assistance, please call 1-800-864 Monday through Friday 7:30 am to 4:30 pm CST. Proof of purchase will be required.
  • Page 7 5.Attach Hose to Jet Tube – Insert end of hose into threaded hole at the bottom of the jet tube. Wrench tighten Assembled View Turn CLOCKWIS E Wrench Tighten Orifice Hole Connect Hose Valve Regulator (HVR) to LP Cylinder – Check that the LP cylinder is upright and the valve is closed by turning the knob as indicated on the top of the valve until fully closed.

  • Page 8: Carbon Monoxide Hazard

    LIQUID PROPANE (LP) CYLINDER This appliance is designed to only operate using Liquid Propane (LP) gas in a self-contained gas supply system (tank). Please follow these instructions for proper specifications and operation. DANGER CARBON MONOXIDE HAZARD This appliance can produce Carbon Monoxide, an odorless and poisonous gas. Never operate this appliance in a building or confined area where ventilation may be restricted.
  • Page 9 WARNING • Do not attempt to alter or disconnect the LP cylinder while the appliance is in use. • Do not move the LP cylinder while it is connected to the appliance. Always disconnect to move the appliance and/or tank. •...
  • Page 10 WARNING WARNING WHEN TO PERFORM A LEAK TEST • After assembling your cooker and before lighting for the first time, even if purchased fully assembled. • Every time the LP gas cylinder is refilled or if any of the gas components are replaced. •...
  • Page 11 PLACEMENT OF COOKER DANGER • This appliance is portable and should not be installed into cabinetry or any other enclosed casing. Any placement or installation of the appliance must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage and Handling of Liquified Petroleum Gases, ANSI/NFPA 58;...

  • Page 12: Lighting Instructions

    LIGHTING INSTRUCTIONS Follow these instructions for safe and proper lighting and re-lighting of the appliance. CAUTION Do not attempt to light this appliance without first folllowing the instructions in this manual for proper assembly, placement, and testing. WARNING • Do not stand with head, body or arms over the appliance when lighting. Loose hair and clothing can catch fire.

  • Page 13: Burner Flame Check

    BURNER FLAME CHECK The regulator valve controls the flame intensity. Practice adjusting the flame height to determine the ideal level. NOTE: the higher the flame intensity, the louder the jet sound. ORANGE BURNER BLUE FLAME Blue flame with little or no yellow flame indicates a proper air/gas mixture and provides the best heat.

  • Page 14: Boiling Instructions

    BOILING INSTRUCTIONS Use these instructions to determine maximum fill level for vessel without a maximum fill line: A. Place the food product on the holder. B. Place the food product and holder into the empty vessel. C. Fill vessel with water just until the food product is completely submerged. There must be a minimum of 8 cm/ 3 in between the water level and top of the vessel.

  • Page 15: Steaming Instructions

    STEAMING INSTRUCTIONS Steaming typically works best with a basket that sits with the bottom approximately 2-3 inches above the bottom of the pot. 1. Pour 3 -4 inches of water into the pot. NOTE: When steaming, your food should not be submerged in the water.

  • Page 16: Maintenance And Care

    MAINTENANCE & CARE Follow these simple steps to keep your appliance looking good and functioning properly for years. 1. Before each use of the appliance, light the cooker and let it run for 5-7 minutes. This initial fire will burn away the manufacturing oil and residue.
  • Page 17 5. Always check the jet tube for any obstructions such as insects or insect nests in the burner. To remove burner obstructions, use a narrow bottle brush or stiff wire bent into a small hook to run up and down the length of the burner tube. Orifice Hole Jet Tube...

  • Page 18: Troubleshooting

    TROUBLE-SHOOTING Contact Barbour International, Inc. customer service at 1-800-864-6194, or visit www.thebayou.com. Symptom Cause Possible Solution Disconnect hose and regulator. Inspect and clean Obstruction in the jet tube cooker. Inspect LP tank, cooker, and HVR assembly for Part of appliance is damaged damage.
  • Page 19 Stainless Steel Stockpots Aluminum Stockpots Accessories Cast Iron Cookware Stainless Steel Fryers Jambalaya Kits Outdoor Smoker Grills and Charcoal...
  • Page 20 FOR OTHER PRODUCTS...
