- Page 1 TITAN II ODG V1 (V3) Models On Demand Grinder Designed in EU. Produced by HeyCafé Co., Ltd. 赫意凯（常州）电器设备有限公司 Building #6, #2 Tenglong Rd, Wujin Economic Development Zone, Jiangsu, 213161 China © HeyCafé Co.LTD. Version 2.0, May 2017...
-
Page 2: Warranty Information
WARNINGS This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the coffee grinder by a person responsible for their safety. Children should be supervised to ensure that they do not play with the grinder. -
Page 3: Table Of Contents
TABLE of CONTENTS 1) Preface……………………………………………………………………………………………….4. 2) Technical Specifications …….………………………………………………………………4. 3) General Description ……………………………………………………………………..……4. 4) Unpacking and installation ………………………………………………………………..5. 5) Operation……………………………………………………………………………………………7. 6) Safety devices…………………………………………………………………………………….9. 7) Safety instructions………………………………………………………………………….….10. 8) Maintenance and service…………………………………….……….…………………….10. 9) Cleaning…………………….…………………………………………………….……………….10. 10) Remarks and important details………………….…………………….……………….13. © HeyCafé Co.LTD. Version 2.0, May 2017... -
Page 4: Preface
1) PREFACE Congratulations for purchasing the Titan II ‘On Demand Grinder’. The Titan II is a commercial appliance to be used in coffee shops, espresso bars, hotels, restaurants, etc. The Titan II grinds whole been roasted coffee into variable, user selectable (from super fine to course) coffee powder and will dose It to your espresso machine Porta Filter or any other means of storage. -
Page 5: Unpacking And Installation
4) UNPACK and INSTALLATION: Warning: Grinder’s entire technical handling operations such as installation, maintenance, or service should be performed by certified personnel or by your local dealer. After opening the box, make sure that the appliance is intact and that there is no visible damage. If there is any doubt, DONOT use the appliance and call your local dealer for further assistance. - Page 6 Install the beans hopper firmly into its position on top of the body inside the top grindstone holder. Fasten the hopper to the appliance body by means of the supplied 2mm Allen screw and key. (fig.4.5) Make sure that the screw is inserted completely through the back hole on the hopper’s crown. Fig4.5 ...
- Page 7 5) OPERATION for V1 models (for V3 models jump forward to page 8) Grinding coffee: Single cup mode selector LCD display Double cup mode selector Continues mode selector Counter selector button Programming dial Fig 5.1 Before start grinding coffee please spend few minutes to learn and understand the concept of the Titan On demand grinding controller (fig.
- Page 8 Dose counting LCD: The Titan ODG V1 grinder is equipped with 3 independent dosing counters. In order to view the content of each counter, a single press on the counter’s selector will display the next counter’s content and at the same time the relative counter’s LED will turn on.
-
Page 9: Operation
Fig. 5.3 fig 5.4 (V3 ONLY) 5) OPERATION (for V3 models only) Grinding coffee with Titan V3 On Demand Grinder: Automatic mode Continues mode selector Power indicator Fig 5.1 A Modes of operation: The HC-600 ODG V3 grinder is installed with a simple operating main switch consisting of 2 running modes. (fig. 5.1 A) ... - Page 10 Operating intervals: In order to avoid over heating of grindstones and grinding chamber (resulting unnecessary heating of the coffee) the manufacturer is recommending using the appliance continuously for short intervals of a few minutes each. Never exceed 10 minutes of continues grinding (or more than 1.5 kg of coffee beans). Adjusting coffee grinding ...
-
Page 11: Safety Devices
6) SAFETY DEVICES A) Thermal overload protection In order to eliminate the risk of fire, the motor is equipped with an overheat protection device which will cutoff the motor’s power supply should it reach a high temperature. In the event that the thermal protection is tripped as a result of malfunction (e.g.: jammed grindstones, worn out bearings, foreign object in grinding chamber, etc.) the appliance main switch should be turned off immediately and the main power plug must be disconnected. -
Page 12: Safety Instructions
7) SAFETY INSTRUCTIONS NEVER OPERATE THE GRINDER IF THE BEAN HOPPER IS NOT FULLY SECURED TO THE TOP GRINDSTONE HOLDER. BEFORE REMOVING THE HOPPER FOR ANY REASON MAKE SURE TO DISCONNECT THE POWER SUPPLY. AVOID CLEARING FOREIGN OBJECTS FROM THE GRINDING CHAMBER OR HOPPER WHEN THE APPLIANCE IS PLUGGED INTO A POWER SOCKET. -
Page 13: Version 2.0, May
Cleaning the bean hopper Take off the bean hopper (by releasing Bean Hopper safety screw, Fig.4-3) and rinse it thoroughly with water and soap. As the bean hopper is made of clear polymer, use only liquid detergent (free of abrasive components) and soft sponge. - Page 14 Only skilled technical personnel should be allowed to perform grindstone removal and assembly. After all cleaning and replacing tasks are through make sure to assemble all of the parts and safety screws the same way as they were disconnected. If anything does not fit back together or there are some leftover parts, do not attempt to operate the appliance, call for the assistance of your technician.
- Page 15 Add your remarks here Date Event Remark Purchasing Important details and telephone numbers: Local dealer Address: ________________________________________________________________ Telephone number: ____________________Fax number:_______________________ Technician mobile number: ____________________name: __________________ Coffee beans supplier details:_________________________________________________________________ Telephone number: ____________________Fax number:_______________________ © HeyCafé Co.LTD. Version 2.0, May 2017...
