- Page 1 Original instructions Allround Grinder Jack www.heycafe.com...
-
Page 2: Table Of Contents
Original instructions Contents Overview ........3 Cleaning ......... 14 Cleaning the surface Scope of delivery .....5 underneath the grinder..14 General information ....6 Cleaning the casing ....15 Reading and storing Cleaning the bean hopper ..15 the instructions ......6 Cleaning the Explanation of symbols used ...6 grinding mechanism .... -
Page 3: Overview
Jack Allround Grinder | EN Overview... - Page 4 Original instructions...
-
Page 5: Scope Of Delivery
Jack Allround Grinder | EN Scope of delivery No. Name Bean hopper (with lid) Slider Grinding degree adjustment (with grinding degree scale) Spout cover (removable; with overview of grinding degree guide values) On/off switch Power cable (with power plug) Knurled screws (left and right) -
Page 6: General Information
European Union. Please also observe the guidelines and laws that apply in your country. For greater clarity, the Allround Grinder Jack will be referred to simply as the “grinder” below. Retain these original instructions for future reference. Please also pass these original instructions on to subsequent owners and users of the grinder. -
Page 7: Safety
Jack Allround Grinder | EN UKCA mark: Products marked with this symbol comply with the electrical product safety requirements of the United Kingdom of Great Britain and Northern Ireland. ETL Listed test seal: Products marked with this symbol meet the requirements for electrical product safety in the United States of America. -
Page 8: Safety Information
Original instructions Safety information WARNING! Risk of electric shock! Improper use, incorrect electrical installation, or a voltage that is too high can all lead to electric shock. – Connect the grinder only if the supply voltage of the socket complies with the information indicated on the type plate. –... - Page 9 Jack Allround Grinder | EN – Keep children away from the grinder. – Make sure that children do not insert any objects into the grinder. – If you are not currently using the grinder, if you are cleaning it, or if there is a malfunction, switch the grinder off and remove the power plug from the socket.
-
Page 10: Before Using For The First Time
Original instructions – Do not reach into the grinding mechanism or the spout of the grinding mechanism from above with unprotected fingers under any circumstances. – Do not insert any objects in the grinding mechanism. – Always switch the grinder off (on/off switch in the OFF position) and remove the power plug from the socket, before you carry out cleaning and maintenance work on the grinder. -
Page 11: Inserting The Hopper
Jack Allround Grinder | EN Inserting the hopper 1. Place the bean hopper (1) on the grinder (see Fig. B). Ensure that the hole in the bottom edge of the bean hopper is located on the same side as the securing screw (13) on the bean hopper intake (12). -
Page 12: Changing The Coffee Bean Type
Original instructions Changing the coffee bean type 1. Close the bean hopper (1) towards the grinding mechanism by pushing in the slider (2). 2. Grind the coffee beans that remain in the grinding mechanism until the grinder runs empty. 3. Switch off the grinder (on/off switch (5) in the OFF position) and remove the power plug (6) from the socket. -
Page 13: Grinding Process
Jack Allround Grinder | EN Only reduce the grinding degree when the grinder is in operation. To avoid/eliminate imbalances when setting the grinding degree, it is advisable to set a coarser grinding degree to begin with and then reduce the grinding degree adjustment to the desired finer grinding degree from there. -
Page 14: Cleaning
Original instructions Cleaning CAUTION! Risk of injury! The grinder can fall over and cause injury when it is being moved. – Always place the grinder on a stable surface that will not tilt. – Ask another person for help if the grinder is too heavy. NOTE! Risk of short-circuit! Water penetrating the grinder can cause a short-circuit. -
Page 15: Cleaning The Casing
Jack Allround Grinder | EN Cleaning the casing Clean the housing as required, but at least once a week or once per 10 kg of ground coffee beans. 1. Switch off the grinder (on/off switch (5) in the OFF position) and remove the power plug (6) from the socket. -
Page 16: Cleaning The Grinding Mechanism
The manufacturer recommends using the GRINDZ grinder cleaner. For more information about GRINDZ , visit www.heycafe.com. The grinding mechanism should be cleaned every 2–5 days. 1. Close the bean hopper (1) towards the grinding mechanism by pushing in the slider (2). - Page 17 Jack Allround Grinder | EN 3. Disassemble the spout (10) by removing the stainless steel spout from the grinder housing spout (see Fig. F). Push the stainless steel spout upwards and turn it clockwise to detach it. Then pull the stainless steel spout off the grinder housing spout downwards.
-
Page 18: Troubleshooting
Original instructions Troubleshooting Problem Cause Solution • The power t Insert the power plug into a properly The grinder plug has not installed socket. is not been inserted. grinding. • The back-up t Check the back-up fuse. Return it to its fuse has tripped. - Page 19 Jack Allround Grinder | EN Problem Cause Solution • The grinding t Contact your supplier (see “Maintenance and The grinder discs are worn service” section). is not out or need to grinding be readjusted. finely enough. • The spout and t Use the brush to clean the spout with the grinder’s...
-
Page 20: Technical Data
Original instructions Technical data Model: Jack Voltage / frequency: 220–240 V AC; 50/60 Hz 100–127 V AC; 50/60 Hz Power: 200 W Protection class: Protection type (grinder): IPX1 Back-up fuse: 16 A-slow Idle speed: 1200 rpm (220–240 V AC) 1400 rpm (100–127 V AC) Grinding capacity*: 1.5 -3.0 g/s (Mocha – French Press) Max. -
Page 21: Maintenance And Service
• For all inquiries and spare parts orders, please be sure to include the article and serial number as stated on the grinder’s type plate. You can also refer to the videos about the Jack on the YouTube channel of HeyCafé for useful information on handling the grinder. - Page 24 Hemro International AG Thurgauerstrasse 80 | 8050 Zurich, Switzerland T: +41 44 864 18 00 | F: +41 44 864 18 01 info@hemrogroup.com | www.hemrogroup.com...
