JLCooper Electronics gBOX User Manual

Ethernet to gpi interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
gBOX
E t h e r n e t t o G P I I n t e r f a c e
U s e r s M a n u a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the gBOX and is the answer not in the manual?

Questions and answers

Related Manuals for JLCooper Electronics gBOX

Summary of Contents for JLCooper Electronics gBOX

  • Page 1 E t h e r n e t t o G P I I n t e r f a c e U s e r s M a n u a l...
  • Page 2 I/O are trademarks of JLCooper Electronics. All other brand names are the property of their respective owners. gBOX User’s Manual, Second Edition Part Number 932126 ©2017 JLCooper Electronics, 142 Arena Street, El Segundo, CA 90245 USA...

  • Page 3: Table Of Contents

    Ethernet .................. 13 Serial ..................14 GPI Port Pinouts ..............16 GPI Port Circuitry Details ............. 17 Using with eBOX I/O ..............19 Power .................... 20 Troubleshooting ................21 Care and Service ............... 22 JLCooper Electronics Limited Warranty ......... 23...

  • Page 4: Introduction

    48 GPI (General Purpose Interface) inputs and outputs to 100/10baseT Ethernet or a serial interface. Up to 8 gBOXes may be slaved off a master gBOX to convert up to a total of 432 GPI inputs and outputs. The gBOX communicates over standard TCP/IP which allows it be used with any host computer running any operating system that uses TCP/IP protocol.

  • Page 5: Setup

    Setup Unpacking The gBOX package will contain the following items: • gBOX • Power Supply • This Users Manual • Four rubber feet Connections The gBOX connections are straightforward: 1. Plug the power supply into the gBOX. 2. Install an Ethernet or serial interface into the interface slot.
  • Page 6 GPI 16 GPI 40 GPI 17 GPI 41 GPI 18 GPI 42 GPI 19 GPI 43 GPI 20 GPI 44 GPI 21 GPI 45 GPI 22 GPI 46 GPI 23 GPI 47 GPI 24 GPI 48 gBOX Master GPI In/Out Pinout...

  • Page 7: Configuration

    • Server • Client The DIP switches are read only at power on so the gBOX must be power cycled for the changes to take effect. Serial When the gBOX has a serial Interface installed, it has just one distinct mode of operation. This is GPI to serial conversion.

  • Page 8: Ethernet Interface

    Mode Selection When DIP switch 5 on the left side is in the Off position, the gBOX behaves as a server. That is, the gBOX waits for a device such as a host computer or client gBOX to establish a connection to it.

  • Page 9: Server Mode

    Server Mode In the Server Mode of operation, DIP Switches 1, 2, 3 and 4 on the left side set the IP address of the gBOX. The units IP address is set according to the table below. 192.168.254.102 192.168.254.104 192.168.254.106 192.168.254.108...

  • Page 10: Client Mode

    Client Mode In the Client Mode of operation, DIP Switches 1, 2, 3 and 4 on the left side set the IP address of the gBOX. The units IP address is set according to the table below. 192.168.254.103 192.168.254.105 192.168.254.107 192.168.254.109...

  • Page 11: Serial Interface

    The gBOX can be daisy chained to allow one Ethernet or Serial connection to accommodate up to 432 GPI Inputs and Outputs. When the rear panel slot is vacant, the gBOX assumes it is an expander unit and uses the rear panel DIP switches 1, 2 and 3 on the left side to set the expander ID.

  • Page 12: Gbox Security

    AND have a matching password. The DIP switches are read only at power on so the gBOX must be power cycled for any changes to take effect. This security mechanism is only used in gBOX Server and gBOX Client modes.

  • Page 13: Technical Reference

    Electrical Connections Ethernet This gBOX port is just like Ethernet ports on a computer, to connect it to a hub, switch or router, use a straight through cable. To connect it to another gBOX or computer, use a crossover cable.

  • Page 14: Serial

    Serial When the 920466 Standard RS-232 Interface Card or the 920465 Standard RS-422 Interface Card is installed the unit is a simple GPI to serial converter. The pinout of the serial interface is detailed in the table below. Interface RS-232C RS-422A RS-422A “Mach”...
  • Page 15 Serial port communications occurs with the following parameters: • Bit rate: 38400 bits/sec • Start bits: • Data bits: • Stop bits: The parity of the serial port can be set on the leftmost set of DIP switches on the rear panel. The parity is set using the following table.

  • Page 16: Gpi Port Pinouts

    GPI In ports to each other so it can be shown on the GPI Out port on the remote gBOX. After that, changes to a GPI In port will cause a gBOX to send a GPI message to the remote gBOX.

  • Page 17: Gpi Port Circuitry Details

    The gBOX GPI input and output circuits are detailed in the following section. The inputs of the gBOX GPI ports are CMOS inputs. The input circuitry has a 4700 ohm pullup resistor to +5 volts as referenced to pin 1 of the GPI Input Port.
  • Page 18 The outputs of the gBOX GPI ports are also CMOS. The output signal is referenced to pin 1 of the GPI Output Port. The GPI Outputs are rated to +/- 6mA. If this is not sufficient for your application, consider using the eBOX I/O.

  • Page 19: Using With Ebox I/O

    The eBOX I/O comes with a pair of cables that allow you to connect it to a single eBOX I/O to a gBOX. Up to six eBOX I/Os can be used with a single gBOX. To connect two or three eBOX...

  • Page 20: Power

    North America 561026-4 Europe 561026-4 Approved Power Supplies Warning: Using a power supply other than the units specified in the above table can result in damage to the gBOX and/or other equipment, which is not covered by the JLCooper Factory Warranty.

  • Page 21: Troubleshooting

    Troubleshooting If for some reason the gBOX does not give you the expected results, take a moment to do some investigating. The most important concept is that you have your gBOX connected properly as outlined in Installation and Use. Take a moment to double check your setup.

  • Page 22: Care And Service

    If you are using the gBOX Configuration Utility, be sure to reboot the gBOX for the settings to take effect A common problem is forgetting to turn the power switch on or turning the unit on after the software application has launched.

  • Page 23: Jlcooper Electronics Limited Warranty

    JLCooper Electronics Limited Warranty JLCooper Electronics ("JLCooper") warrants this product to be free of defects in materials or workmanship for a period of 12 months from the date of purchase. This warranty is non-transferable and the benefits apply only to the original owner. Proof of purchase in the form of an itemized sales receipt is required for warranty coverage.
