Configure via Web Browser
1. Connect your computer to the router (Wired or Wireless)
Wired
Turn off the Wi-Fi on your computer and connect the devices as shown below.
Ethernet cable
Wireless
a. Find the SSID (Network Name) and Wireless Password printed on the label at the
bottom of the router.
b. Click the network icon of your computer or go to Wi-Fi Setting of your smart
device, and then select the SSID to join the network.
Computer
< Settings
Connections are available
Wi-Fi
Wireless Network Connection
or
CHOOSE A NETWORK...
TP-LINK_XXXX
TP-LINK_XXXX_5G
TP-LINK_XXXX
√ Connect automatically Connect
TP-LINK_XXXX_5G
Other...
2.
Configure the router using a web browser
Enter http://tplinkwifi.net or http://192.168.0.1 in the address bar of a web
A
browser. Use admin for both username and password, and then click Login.
Note: If the login window does not appear, please refer to FAQ > Q1.
http://tplinkwifi.net
admin
admin
Login
Create a new username and password and click Confirm. Then follow the
B
step-by-step instructions of the Quick Setup to complete the initial configuration.
Internet Connection Type
Time Zone
Note: If you are not sure of the Internet Connection Type, please click Auto Detect.
Moreover, the TP-LINK router is equipped with various features, such as Guest Network, Parental
Controls, Access Control, etc. For details, please refer to the User Manual at www.tp-link.com.
Tether App
TP-LINK Tether app provides a simple, intuitive way to access and manage your router.
You can block unwelcome devices, set up Parental Controls, configure your wireless
Smart Device
settings and more.
Wi-Fi
Scan the QR code to download the TP-LINK Tether
app from the Apple App Store or Google Play.
USB Features
Use the USB port for media sharing, storage sharing and printer sharing across your
local network. You can also set up an FTP server to access your files remotely through
the Internet.
USB sharing port
Remote Access
via FTP Server
To learn more about the USB features, please visit
http://www.tp-link.com/app/usb/, or simply scan the QR code.
Wireless Settings Test Internet Connection
Summary
Local Storage
Media Sharing
Printer Sharing
Sharing
FAQ (Frequently Asked Questions)
Q1. What can I do if the login window does not appear?
If the computer is set to a static or fixed IP address, change the setting to
obtain an IP address automatically.
Verify that http://tplinkwifi.net or http://192.168.0.1 is correctly entered in
the web browser. Alternatively, enter http://192.168.1.1 in the web browser.
Use another web browser and try again.
Reboot your router and try again.
Disable and enable the the network adapter in use again.
Q2. What can I do if I cannot access the Internet?
Check if the Internet is working properly by connecting a computer directly
to the modem via an Ethernet cable. If it is not, contact your Internet Service
Provider.
Log into the Web Management page of the router, and go to the Basic > Network
Map page to check whether the IP address is valid or not. If it is, please run the
Quick Setup again; otherwise, recheck the hardware connection.
Reboot your router and try again.
For cable modem users, reboot the modem first. If the problem still exists,
log into the web management page of the router, go to Advanced >
Network > Internet > MAC Clone, click Use Current Computer MAC
Address and then click Save.
Q3. How do I restore the router to its factory default settings?
With the router powered on, press and hold the Reset button on the back
until the LED blinks.
Log into the web management page of the router, go to Advanced > System
Tools > Backup & Restore > Factory Default Restore, and click Factory
Restore. The router will restore and reboot automatically.
Q4. What can I do if I forgot my Web Management password?
Refer to FAQ > Q3 to reset the router, and then use the default admin (all
lowercase) for both username and password to log in.
Q5. What can I do if I forgot my wireless network password?
If you have not changed the default Wireless Password, it can be found on the
label of the router.
Connect a computer directly to the router using an Ethernet cable. Log into the
Web Management page, and go to Basic > Wireless to retrieve or reset your
wireless password.
If your questions are not listed here, please refer to the support page at
www.tp-link.com.
