Petsafe Healthy Pet Simply Feed Quick Manual

ICON FUNCTION
TIME INDICATOR - Displays current time or time of next
05:30 pm
18:00
scheduled meal. Can be set to 12 hour or 24 hour format.
BUTTON LOCK INDICATOR - Displays when 5-Button Navigation
is disabled. Buttons automatically lock when not in use.
BATTERY INDICATOR - Displays when D-cell alkaline batteries are
in use and life status.
POWER ADAPTER INDICATOR - Displays when power adapter is
connected to pet feeder.
MEAL NUMBER INDICATOR - Displays which meal is being
2
programmed. Up to 12 meals can be scheduled.
MEAL SIZE INDICATOR - Displays portion for meal number being
programmed or portion for next scheduled meal to be dispensed.
1- / cup
1
8
30 ml
Can be set to cups if using 12 hour time format or milliliters if using
24 hour time format.
DOG - Feeding schedule is set to default dog, which is two 2-cup
Dog
(473 ml) meals per day at 8 am (08:00) and 5 pm (17:00).
CAT - Feeding schedule is set to default cat, which is two ¼-cup
Cat
(59 ml) meals per day at 8 am (08:00) and 5 pm (17:00).
USER - Feeding schedule is set to user mode with customized
Usr
meal numbers, times and portions.
SLOW FEED INDICATOR - Displays if feeder is set to Slow Feed
Mode, which dispenses all scheduled meals at a slower rate over a
15 minute period.
PAUSE FEED INDICATOR - Feeding schedules are suspended
and feeder will not dispense food until pause is removed.
IMMEDIATE FEED - Push to immediately dispense next
scheduled meal. Only one meal in a row can be immediately fed. A
meal must be automatically dispensed before immediate feed can
be used again.
TIME - Push to view current time or push and hold to set clock.

ICON QUICK GUIDE
