Escort Redline Ex Quick Reference

Settings & Preferences
Press and hold the MARK and SENS buttons to access Preferences. To exit Preferences, simply wait a few
seconds without pressing a button. The unit will display Completed to confirm your selections.
Press MARK to go from Press VOLUME + or – to change
one category to the next your setting within a category
Advanced*
User Mode Access and customize all Settings and Preferences
Novice Access and customize units and display color, (all other
Settings are set to factory defaults)
NOTE: Switch back to advance mode to view all Preferences.
Pilot Scan Bar* Scanning Bar with Full Word.
Full Word Full Word: Auto, Auto NoX, AutoLoK or Highway
Red*/Amber/Blue/Green
Display Color Set color to match your vehicle's dash display
Speed Display On* Displays current speed
Off Displays battery voltage
Cruise Alert 20 mph* Offers double beep alert tones below specified speed
Off / 20-160 mph
Over Speed 70 mph* Reminds you when you exceed a specified speed
Off / 20-160 mph
Meter Mode Standard* Single band with bar graph of signal strength
Spec
Single band with numeric frequency
Expert Multiple bands with bar graph of signal strengths
Simple
Simple messages replace bands:
Caution (if traveling below cruise alert limit)
Slow Down
(if traveling above cruise alert limit)
Tones Standard* Standard ESCORT alert tones
Mild Mild doorbell chime alert tones
AutoMute AutoMute Low / Automatically reduces audio to preferred volume
Med* / High / Off during alert
AutoLearn On* / Off Automatically stores and locks out false alarms
Alert Lamp On*/Band/Off Turn the Alert Lamp on, off, or select band mode for
color-coded alerts.
X = green, K = blue, Ka/Laser = red
English* / Metric
Units Units for distance and speed
Language English* / Espanol Language for voice and text
Voice On* / Off Voice announcements
GPS Filter On* / Off Enables GPS-powered features
7
AutoPower Off Power turns on or off depending on your vehicle's ignition
type (constant power or switched)
1 Hour Powers off automatically after 1 hour
2 Hours Powers off automatically after 2 hours NOTE: AutoPower only works with
4 Hours* Powers off automatically after 4 hours constant power ignition.
8 Hours Powers off automatically after 8 hours
NOTE: If AutoPower is on, to save screen life the display screen goes blank after 30 minutes
without moving. Display screen will turn on automatically after you reach 10MPH.
Band Enables Default* Default settings for North America
Modified
Customize the bands you want to monitor
Press SENS to go from one Press VOLUME + or – to change
band category to the next your setting within a category
X Band On* / Off
K Band On*/ Off Freq: 23.950 -24.250 GHz
NOTE: When K Band is off, you can select separate segments of the band to turn on or off.
KN1 On* / Off Freq: 24.050 - 24.110 Ghz
On* / Off
KN2 Freq: 24.110 - 24.175 Ghz
KN3 On* / Off Freq: 24.175 - 24.250 Ghz
KN4 On* / Off Freq: 23.950 - 24.050 Ghz
Strelka On / Off* Strelka detection
MultaRadar CD On / Off* MultaRadar CD detection
MultaRadar CT On / Off* MultaRadar CT detection
Gatso On / Off* Gatso detection
On* / Off
Ka Band Freq: 33.400-36.000 Ghz
NOTE: When Ka Band is off, you can select separate segments of the band to turn on and off.
KaN1 On* / Off Freq: 33.392 - 33.704 Ghz KaN6 On* / Off Freq: 34.806 - 35.166 Ghz
KaN2 On* / Off Freq: 33.704 - 33.896 Ghz KaN7 On* / Off Freq: 35.143 - 35.383 Ghz
KaN3 On* / Off Freq: 33.886 - 34.198 Ghz KaN8 On* / Off Freq: 35.378 - 35.618 Ghz
KaN4 On* / Off Freq: 34.184 - 34.592 Ghz KaN9 On* / Off Freq: 35.595 - 35.835 Ghz
KaN5 On* / Off Freq: 34.592 - 34.808 Ghz KaN10 On* / Off Freq: 35.830 - 35.998 Ghz
On / Off*
Ka-POP
Laser On* / Off
TSR On* / Off Automatically rejects traffic flow sensors-monitoring false alarms
RDR On* / Off Radar Detector Rejection
8
Marker Enables Default* Default settings
Modified Customize the types of locations you want to mark for future reference
Press SENS to go from one Press VOLUME + or – to change
marker category to the next your setting within a category
Other On* / Off Other location
On* / Off
Redlight Red light camera
Red & Speed On* / Off Red light & speed camera
Speed Cam On* / Off Speed camera
Speed Trp On* / Off Speed trap
Air Patrol On / Off* Known aircraft patroled areas
NOTE: User cannot mark an air patrol location.
Clear Locations Marked Clear all user Marked locations. Press SENS button to confirm
Lockouts
Clear all lockouts. Press SENS button to confirm
Defender Clear all DEFENDER data. Press SENS button to confirm
Format Clear DEFENDER database, all markers, and all lockouts
Press SENS button to confirm
*Default Setting
Notes for Settings & Preferences
For descriptions of features and functions available when connected to ESCORT Live, visit
EscortRadar.com and download the RedLine EX Owner's Manual.
To view serial number and software revision press MARK and MUTE while powering on detector.
To restore RedLine EX to its original factory Settings, press and hold MARK and BRT while turning the
power on. A "Restored" message will display, acknowledging the reset.
Software Updates
RedLine EX's red light and speed camera DEFENDER database is easily updated using our exclusive
detector software tools found on our web site. Firmware, or the operating software for the detector,
can also be updated using these tools.
In order to have access to these updates, please register your RedLine EX at www.EscortRadar.com.
Once registered, you will receive email notifications that updates are now available for your
database or firmware. To handle your software and DEFENDER updates you need to connect your
RedLine EX to a computer first. You can connect RedLine EX to a computer via USB A / Mini B cable
(not included).
9
