Operating instructions

GK17TIYSZ | GK27TIYSZ
Teppan Yaki

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GK17TIYSZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-ZUG GK17TIYSZ

Summary of Contents for V-ZUG GK17TIYSZ

  • Page 1: Operating Instructions

    Operating instructions GK17TIYSZ | GK27TIYSZ Teppan Yaki...
  • Page 2 The product family (model number) corresponds to the first alphanumerics on the identification plate. These operating instructions apply to: Type Product family GK17TIYSZ 31076 GK27TIYSZ 31077 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2017...

  • Page 3: Table Of Contents

    Contents  2 1 Safety precautions  5 Symbols used ...................... 5 General safety precautions .................  6 Appliance-specific safety precautions...............  7 Instructions for use .................... 8 2 Disposal  10 3 Using for the first time  11 4 Your appliance  12 Appliance overview..................... 12 Accessories supplied .................. 12 Operating and display elements .............. 13 5 Operating the appliance...
  • Page 4 11 Index  32 12 Notes  34 13 Service & Support  35...

  • Page 5: Safety Precautions

    Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in damage to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions ▸...

  • Page 6: General Safety Precautions

    1 Safety precautions General safety precautions ▪ Read the operating instructions before using the appliance for the first time! ▪ This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental cap- abilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance and have understood the hazards involved.

  • Page 7: Appliance-Specific Safety Precautions

    1 Safety precautions Appliance-specific safety precautions ▪ WARNING: If the surface is cracked or the control panel glass is damaged, switch the appliance off and disconnect it from the mains to avoid possible electric shock. ▪ Accessible parts can get hot during use. Children under 8 years of age must not operate the appliance unless they are constantly supervised.

  • Page 8: Instructions For Use

    1 Safety precautions Instructions for use Before using for the first time ▪ The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/ electrician carry out the necessary work. Correct use ▪...
  • Page 9 1 Safety precautions Caution: Fire hazard! ▪ The frying zones become very hot. Do not rest any objects on the teppan yaki. ▪ Do not store or use corrosive, chemical or flammable cleaning agents or products underneath or near to this household appliance. Caution: Burns hazard ▪...

  • Page 10: Disposal

    Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection ▪ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety ▪...

  • Page 11: Using For The First Time

    Using for the first time The appliance must be installed and connected to the electricity sup- ply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. A frying zone can give off an unpleasant smell during the first few hours of use.

  • Page 12: Your Appliance

    Your appliance Appliance overview GK17TIYSZ GK27TIYSZ Frying area with 2 separately Frying area with 2 separately heatable frying zones heatable frying zones Accessories supplied ▪ Cooking bell, 250 mm in diameter ▪ 2 spatulas...

  • Page 13: Operating And Display Elements

    4 Your appliance Operating and display elements 1 2 3 Buttons Appliance ON/OFF Timer/Function as minus button Slider Pause cooking ON/OFF and (for setting the power level) restore function Operating time/Function as Multi-function button/ plus button Temperature selector Wipe protection ON/OFF and OptiClean Displays Heating-up/cooling-down/residual-heat indicator...

  • Page 14: Operating The Appliance

    Operating the appliance Switching the appliance on and off All the appliances are operated in the same way. ▸ To switch the appliance on: Depress the button for 1 second. – flashes in the temperature display. – If no other entry is made, the appliance switches off again after about 10 seconds for safety reasons.

  • Page 15: Overview Of Frying Temperatures

    5 Operating the appliance Overview of frying temperatures Cooking Frying method temperature °C Temperature selector for fish Temperature selector for vegetables Temperature selector for meat Keep warm Prepared food under the cooking bell Gentle frying Vegetables Fruit Joint of meat Fish and seafood, sausages, tofu, grilled cheese Omelettes , egg dishes, fried rice and...

  • Page 16: Bridging Function

    5 Operating the appliance Bridging function The bridging function allows two individual cooking zones lying one behind the other to be switched on together and to be adjusted together. Switching the bridging function on ▸ Touch both sliders at the same time. –...

  • Page 17: Pause Cooking

    5 Operating the appliance Pause cooking With this function, all frying zones that are switched on can be temporarily re- duced to 70 °C for up to 10 minutes. Thereafter, the appliance can continue to be operated using the previous set- tings. ▸...

  • Page 18: Operating Time

    5 Operating the appliance 5.10 Operating time Do not leave the hob unattended during use. Risk of boiling over, burning on and igniting! With the operating time function, a Frying zone switches off automatically after a set time 1 min.–1 h 59 min.. Setting the operating time ▸...
  • Page 19 5 Operating the appliance Switching the operating time function off before time ▸ Touch the button. ▸ Touch the slider for the desired frying zone. ▸ Touch the buttons at the same time. – flashes in the display. – The frying zone continues to run. End of the operating time When the operating time is up –...

  • Page 20: Timer

    5 Operating the appliance 5.11 Timer The timer functions like an egg timer (1 min.–9 h 59 min.). It can be used at any time and independently of all other functions. Setting the timer ▸ Switch the appliance on. ▸ Touch the button.

  • Page 21: Childproof Lock

    5 Operating the appliance 5.12 Childproof lock The childproof lock is to prevent the appliance from being accidentally switched on. Switching the childproof lock on ▸ Switch the appliance on. Ensure all frying zones are switched off. ▸ Touch the buttons at the same time.

  • Page 22: Wipe Protection

    5 Operating the appliance 5.13 Wipe protection This function prevents the power level from being changed accidentally, for in- stance when wiping the control panel with a cloth. ▸ Touch the button. – The indicator light for the button illuminates. ▸...

  • Page 23: User Settings

    User settings The following user settings can be set and stored individually: User setting Setting value Factory setting Acoustic signal volume Medium High Acoustic signal No acoustic signal at end of operating Automatically off after time/timer 10 seconds Automatically off after 1 minute Recommended value Default time 0 minutes...

  • Page 24: Changing User Settings

    6 User settings Changing user settings ▸ With the teppan yaki switched off, simultaneously hold the but- tons depressed for 3 seconds. – An acoustic signal is emitted. ▸ Touch both sliders at the same time. – An acoustic signal is emitted. –...

  • Page 25: Care And Maintenance

    Care and maintenance Clean the appliance only when it has completely cooled down. Burns hazard! Always clean the appliance after use. This prevents food residue from burning on. Dried-on or burned-on food is harder to clean off. Use of improper cleaning techniques can result in damage to the markings or surface.

  • Page 26: Opticlean

    70 °C for 10 minutes. This softens up crusty de- posits, making them easier to remove. Switching OptiClean on ▸ Pour 0.3 l (GK17TIYSZ) or 0.5 l (GK27TIYSZ) water on to the frying surface. ▸ Hold the button depressed for 2 seconds.

  • Page 27: Trouble-Shooting

    Trouble-shooting What to do if … … the appliance is not working and all the displays are dark? Possible cause Solution ▪ The fuse or circuit breaker in ▸ Change the fuse. the house wiring system has ▸ Reset the circuit breaker. tripped.
  • Page 28 8 Trouble-shooting flash alternately in the display? Possible cause Solution ▪ The automatic safety shut-off ▸ Switch the frying zone back on again if was triggered. required. If a frying zone has been running for longer without any settings being changed, the appliance switches the frying zone off automatically, after how much time depends on the temperature set.
  • Page 29 8 Trouble-shooting … and a number are illuminated in the display? Possible cause Solution ▪ Internal error occurred. ▸ Note down the error number. ▸ Note down the serial number (FN) of the appliance. See the identification plate for this. ▸...

  • Page 30: Accessories

    Accessories Please give product family of the appliance and exact designation of the ac- cessory when ordering parts. ▪ Cutting board...

  • Page 31: Technical Data

    Technical data 10.1 Product fiche Model number 31076 Type designation GK17TIYSZ Number of frying zones Frying surfaces B: 31 × B: 31 × T: 17.7 cm T: 17.7 cm Model number 31077 Type designation GK27TIYSZ Number of frying zones Frying surfaces B: 49.8 ×...
  • Page 32 Index Operating time..........18 Changing .......... 18 Accessories ........... 30 Finished.......... 19 Accessories supplied........12 Setting .......... 18 Appliance Several operating times .... 19 Switching on and off ...... 14 Switching off before time .... 19 Appliance-specific safety OptiClean............26 precautions ..........
  • Page 33 11 Index Validity............... 2 Warranty extensions ........35 Where is the identification plate?....11 Wipe protection ..........22...
  • Page 34 Notes...
  • Page 35 V‑ZUG service centre. Technical questions, accessories, warranty extensions V-ZUG is happy to help you with any general administrative or technical queries, to take your orders for accessories and spare parts and to inform you about our progressive ser- vice agreements.
  • Page 36 ▸ Touch the slider for the required frying zone or slide your finger along it to set the frying temperature. To switch frying zone off ▸ Touch « » on the slider. To switch appliance off ▸ Touch the button. 1017502-R03 V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug info@vzug.com, www.vzug.com...
