Acura Embedded Systems AcuPanel S22Wi5 Quick Manual

AcuPanel S22Wi5
AcuPanel S22Wi5
Quick Guide
Edition 1.0
Acura Embedded Systems Inc.
Acura Embedded Systems Inc.
21.5" Touch Screen, Ultra Slim
and 3mm Front Bezel
Industrial Panel Computer
with Intel® i5
1. OVERVIEW
AcuPanel S22Wi5 is a 21.5" Wide 1920×1080 LED display rugged and ultra slim panel
PC based on latest generation Intel® Core i5 4460 processors. Its memory default 4
GB can easily upgrade to 8 GB. The design focuses on elements essential for a variety
of industrial applications and environments (Extreme -10°C to 60°C operating
temperature) excluding unneccesary hardware. The architecture is modular which
allows for upgrading and expansions.
2. MAIN FEATURES
•
Top Interface
•
Bottom Interface
WiFi Antenna COM1 COM2
DC Power in
•
Cutout (Unit:mm)
Quick Guide
Power Button
HDMI USB Lineout
USB VGA LAN Mic-In
1
Updated in July 7 /17
