B&B Electronics Parallel Printer Card PIOC User Manual page 5

Table 4 - Hardware I/O Map of AT Class Machines
Hex Address
000-01F
020-03F
040-05F
060-06F
070-07F
080-09F
0A0-0BF
0C0-0DF
0F0-0FF
1F0-1F8
200-20F
258-25F
278-27F
2E8-2EF
2F8-2FF
300-31F
378-37F
380-38F
3A0-3AF
3B0-3BF
3BC-3BE
3C0-3CF
3D0-3D7
3E8-3EF
3F0-3F7
3F8-3FF
Any four byte space not listed in Table 4 and not used by any
other equipment in your system may be used for the parallel port.
Appendix A shows all the possible addresses and their settings.
