B&B Electronics Parallel Printer Card PIOC User Manual page 14

SW1: ......... 1 .....2 . ..... 3..... 4 ........5..... 6..... 7........8 .... X.....X
Addr.: .....A9 .. A8 . ...A7...A6 ..... A5...A4...A3..... A2 .. A1...A0
Weight:..... 2 .....1 . ..... 8..... 4 ........2..... 1..... 8........4 .... 2..... 1
300 ........... 1 .....1 . ..... 0..... 0 ........0..... 0..... 0........0 .... 0..... 0
304 ........... 1 .....1 . ..... 0..... 0 ........0..... 0..... 0........1 .... 0..... 0
308 ........... 1 .....1 . ..... 0..... 0 ........0..... 0..... 1........0 .... 0..... 0
30C ........... 1 .....1 . ..... 0..... 0 ........0..... 0..... 1........1 .... 0..... 0
310 ........... 1 .....1 . ..... 0..... 0 ........0..... 1..... 0........0 .... 0..... 0
314 ........... 1 .....1 . ..... 0..... 0 ........0..... 1..... 0........1 .... 0..... 0
318 ........... 1 .....1 . ..... 0..... 0 ........0..... 1..... 1........0 .... 0..... 0
31C ........... 1 .....1 . ..... 0..... 0 ........0..... 1..... 1........1 .... 0..... 0
320 ........... 1 .....1 . ..... 0..... 0 ........1..... 0..... 0........0 .... 0..... 0
324 ........... 1 .....1 . ..... 0..... 0 ........1..... 0..... 0........1 .... 0..... 0
328 ........... 1 .....1 . ..... 0..... 0 ........1..... 0..... 1........0 .... 0..... 0
32C ........... 1 .....1 . ..... 0..... 0 ........1..... 0..... 1........1 .... 0..... 0
330 ........... 1 .....1 . ..... 0..... 0 ........1..... 1..... 0........0 .... 0..... 0
334 ........... 1 .....1 . ..... 0..... 0 ........1..... 1..... 0........1 .... 0..... 0
338 ........... 1 .....1 . ..... 0..... 0 ........1..... 1..... 1........0 .... 0..... 0
33C ........... 1 .....1 . ..... 0..... 0 ........1..... 1..... 1........1 .... 0..... 0
340 ........... 1 .....1 . ..... 0..... 1 ........0..... 0..... 0........0 .... 0..... 0
344 ........... 1 .....1 . ..... 0..... 1 ........0..... 0..... 0........1 .... 0..... 0
348 ........... 1 .....1 . ..... 0..... 1 ........0..... 0..... 1........0 .... 0..... 0
34C ........... 1 .....1 . ..... 0..... 1 ........0..... 0..... 1........1 .... 0..... 0
350 ........... 1 .....1 . ..... 0..... 1 ........0..... 1..... 0........0 .... 0..... 0
354 ........... 1 .....1 . ..... 0..... 1 ........0..... 1..... 0........1 .... 0..... 0
358 ........... 1 .....1 . ..... 0..... 1 ........0..... 1..... 1........0 .... 0..... 0
35C ........... 1 .....1 . ..... 0..... 1 ........0..... 1..... 1........1 .... 0..... 0
360 ........... 1 .....1 . ..... 0..... 1 ........1..... 0..... 0........0 .... 0..... 0
364 ........... 1 .....1 . ..... 0..... 1 ........1..... 0..... 0........1 .... 0..... 0
368 ........... 1 .....1 . ..... 0..... 1 ........1..... 0..... 1........0 .... 0..... 0
36C ........... 1 .....1 . ..... 0..... 1 ........1..... 0..... 1........1 .... 0..... 0
370 ........... 1 .....1 . ..... 0..... 1 ........1..... 1..... 0........0 .... 0..... 0
374 ........... 1 .....1 . ..... 0..... 1 ........1..... 1..... 0........1 .... 0..... 0
378*........... 1 .....1 . ..... 0..... 1 ........1..... 1..... 1........0 .... 0..... 0
37C ........... 1 .....1 . ..... 0..... 1 ........1..... 1..... 1........1 .... 0..... 0
Documentation Number PIOC2595 Manual 13
