B&B Electronics Parallel Printer Card PIOC User Manual page 15

SW1: ......... 1 .....2 . ..... 3..... 4 ........5..... 6..... 7........8 .... X.....X
Addr.: .....A9 .. A8 . ...A7...A6 ..... A5...A4...A3..... A2 .. A1...A0
Weight:..... 2 .....1 . ..... 8..... 4 ........2..... 1..... 8........4 .... 2..... 1
380 ........... 1 .....1 . ..... 1..... 0 ........0..... 0..... 0........0 .... 0..... 0
384 ........... 1 .....1 . ..... 1..... 0 ........0..... 0..... 0........1 .... 0..... 0
388 ........... 1 .....1 . ..... 1..... 0 ........0..... 0..... 1........0 .... 0..... 0
38C ........... 1 .....1 . ..... 1..... 0 ........0..... 0..... 1........1 .... 0..... 0
390 ........... 1 .....1 . ..... 1..... 0 ........0..... 1..... 0........0 .... 0..... 0
394 ........... 1 .....1 . ..... 1..... 0 ........0..... 1..... 0........1 .... 0..... 0
398 ........... 1 .....1 . ..... 1..... 0 ........0..... 1..... 1........0 .... 0..... 0
39C ........... 1 .....1 . ..... 1..... 0 ........0..... 1..... 1........1 .... 0..... 0
3A0 ........... 1 .....1 . ..... 1..... 0 ........1..... 0..... 0........0 .... 0..... 0
3A4 ........... 1 .....1 . ..... 1..... 0 ........1..... 0..... 0........1 .... 0..... 0
3A8 ........... 1 .....1 . ..... 1..... 0 ........1..... 0..... 1........0 .... 0..... 0
3AC ........... 1 .....1 . ..... 1..... 0 ........1..... 0..... 1........1 .... 0..... 0
3B0 ........... 1 .....1 . ..... 1..... 0 ........1..... 1..... 0........0 .... 0..... 0
3B4 ........... 1 .....1 . ..... 1..... 0 ........1..... 1..... 0........1 .... 0..... 0
3B8 ........... 1 .....1 . ..... 1..... 0 ........1..... 1..... 1........0 .... 0..... 0
3BC*.......... 1 .....1 . ..... 1..... 0 ........1..... 1..... 1........1 .... 0..... 0
3C0 ........... 1 .....1 . ..... 1..... 1 ........0..... 0..... 0........0 .... 0..... 0
3C4 ........... 1 .....1 . ..... 1..... 1 ........0..... 0..... 0........1 .... 0..... 0
3C8 ........... 1 .....1 . ..... 1..... 1 ........0..... 0..... 1........0 .... 0..... 0
3CC........... 1 .....1 . ..... 1..... 1 ........0..... 0..... 1........1 .... 0..... 0
3D0 ........... 1 .....1 . ..... 1..... 1 ........0..... 1..... 0........0 .... 0..... 0
3D4 ........... 1 .....1 . ..... 1..... 1 ........0..... 1..... 0........1 .... 0..... 0
3D8 ........... 1 .....1 . ..... 1..... 1 ........0..... 1..... 1........0 .... 0..... 0
3DC........... 1 .....1 . ..... 1..... 1 ........0..... 1..... 1........1 .... 0..... 0
3E0 ........... 1 .....1 . ..... 1..... 1 ........1..... 0..... 0........0 .... 0..... 0
3E4 ........... 1 .....1 . ..... 1..... 1 ........1..... 0..... 0........1 .... 0..... 0
3E8 ........... 1 .....1 . ..... 1..... 1 ........1..... 0..... 1........0 .... 0..... 0
3EC ........... 1 .....1 . ..... 1..... 1 ........1..... 0..... 1........1 .... 0..... 0
3F0 ........... 1 .....1 . ..... 1..... 1 ........1..... 1..... 0........0 .... 0..... 0
3F4 ........... 1 .....1 . ..... 1..... 1 ........1..... 1..... 0........1 .... 0..... 0
3F8 ........... 1 .....1 . ..... 1..... 1 ........1..... 1..... 1........0 .... 0..... 0
3FC ........... 1 .....1 . ..... 1..... 1 ........1..... 1..... 1........1 .... 0..... 0
14 Documentation Number PIOC2595 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 433-5105
