ADVANCED COMMUNICATIONS & SENSING
2

Getting Started

2.1 Kit Contents

As illustrated in the figure below, the SX1230-11SKA Evaluation kit is composed of:
A pair of SX1211SKA boards
SX1211-11SKA CDROM including all necessary PC software and documentation

2.2 Installation

SX1211SKA Advanced Mode Software Installation
1- Put the CDROM in your computer and browse the contents of the CD.
2- Open the "sx1211starterkitsetupweb.exe" manually. It can be found in the \Installers sub directory of the
CD-ROM.
3- Follow installation guidelines until the process is completed. Please note that .NET Framework 2.0 and the
FTDI USB driver will be automatically installed if not detected on your computer.
4- Connect the SX1211SKA board to the PC via the USB interface.
5- Launch "SX1211SKA" from the Start menu.
6- Click on "Connect" button in toolbar or in File menu.
7- SX1211SKA is now installed and ready to be used.
Revision 0.1 March 2009 © 2009 Semtech Corp.

Figure 2. SX1211SKA Contents

5
User's Guide
SX1211-11SKA
www.semtech.com
