OWNER'S OPERATING MANUAL
1 / 4 h.p.

SPECIFICATIONS:

• Input ...................................... 1/4 h.p. 180 watt
• No Load Speed...................... 625 - 2500 r.p.m.
• Drilling Capacity .................... 13mm
• Chuck Capacity ...................... 13mm
• Spindle Taper ........................ MT2
• Spindle Travel........................ 50mm
• Spindle Speeds .................... 5
• Table Size .............................. 160 x 160mm
• Base Size................................ 285 x 185mm
• Weight .................................... 19kg
This Bench Drill Press is designed for light consumer use.
It is NOT designed for trade or industrial use and is not
THANKYOU FOR BUYING A RYOBI DRILL
Your new drill has been engineered and manufactured to Ryobi's high standard for dependability, ease
of operation and operator safety. Properly cared for, it will give you years of rugged, trouble free
performance.
CAUTION: Carefully read through this entire owner's manual before using your drill.
Pay close attention to the Rules for Safe Operation, Warnings and Cautions. If you use your drill properly
and only for what it is intended, you will enjoy years of safe, reliable service.
Thank you again for buying Ryobi tools.
5
SPEED BENCH DRILL PRESS
MODEL BD513
IMPORTANT NOTICE:
covered by warranty for use in these applications.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
