- Page 1 RS112 Rugged Server RS112 Rugged Server User Guide The most trusted provider for operational, deployable, and high reliability computing applications. ISO 9001:2008 & CRYSTAL GROUP INC. AS9100C:2009 CERTIFIED QMS DOC-00224 REV D ©2015 BY CRYSTAL GROUP INC. ALL RIGHTS RESERVED.
- Page 2 RS112 Rugged Server...
-
Page 3: Table Of Contents
SPECIFICATIONS INSTALLING THE PRODUCT GROUNDING RACK MOUNTING PRECAUTIONS INSTALLING IN AN EQUIPMENT RACK OPERATING THE PRODUCT CONNECTING TO THE POWER SOURCE POWERING THE SERVER ON MAINTAINING THE PRODUCT DRIVER UPDATES CHASSIS ACCESS RS112 Rugged Server User Guide Page of 26... - Page 4 CHASSIS VIEWS EXPANSION/RISER CARD REMOVAL AND REPLACEMENT HARD DRIVE REMOVAL AND REPLACEMENT MEMORY REMOVAL AND REPLACEMENT TROUBLESHOOTING AVAILABLE WARRANTY CRYSTAL GROUP LIMITED WARRANTY LEGAL INFORMATION COPYRIGHTS AND TRADEMARKS DISCLAIMERS CERTIFICATIONS AND LICENSES RS112 Rugged Server User Guide Page of 26...
- Page 5 RS112 Rugged Server We Thank You! From all of us at Crystal Group Inc., THANK YOU for your purchase of the RS112. Our customers are the lifeline that keeps Crystal going. That is why it is extremely important to us that our customers are 100% satisfied with their product choice.
-
Page 6: Safety
A note indicates important information that helps make better use of the equipment. WARNING A warning indicates a potential for property damage, personal injury, or death. CAUTION Caution indicates potential damage to hardware or loss of data if instructions are not followed. RS112 Rugged Server User Guide Page of 2... -
Page 7: Handling Precautions
Do not touch the input/output connector pins. BATTERY DISPOSAL The following applies to any battery that might be on any board installed in the RS112: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. -
Page 8: Contact Information
After hours messaging service is available with a less than 30-minutes response time. Within the United States: 800-378-1636 International Number: 1+319-378-1636 Email Address: support@crystalrugged.com Request a Form Under Tech Support: http://www.crystalrugged.com For Up-to-the-minute Crystal Products Information: http://www.crystalrugged.com RS112 Rugged Server User Guide Page of 26... -
Page 9: Product Information
RS112 Rugged Server Product Information OVERVIEW The Crystal RS112 is a compact one rack unit (R/U) computer in a (1U) high by wide by deep chassis that is designed for use in a rack mount enclosure (see section Installing the Product for more information) or used as a stand- alone unit. - Page 10 X9DRL-iF, LGA2011 XEON, ATX, 2LAN1000, VGA, 1 PCI 3.3V, 4 PCI-E X8, 1 PCI-E X11, IPMI, IPKVM, SATARAIDX9, SATA3X2 Military Standards For a complete list of Military Standards visit the Crystal Group website at: http://www.crystalrugged.com (Locate product under the PRODUCTS selection). Commercial Standards Commercial standards are based on the National Electric Code (NFPA70- National Fire Protection Association).
-
Page 11: Installing The Product
Installing the Product GROUNDING AC Version- to ensure a good earth ground, the RS112 should be used with a UL listed three-conductor power cord connected to a three-conductor grounded power source. DC Version- input installations- use only approved copper connectors. -
Page 12: Installing In An Equipment Rack
Line up eight holes on the sides of the rear mounting brackets with eight holes on the sides of the RS112 chassis and secure to chassis with 16 (eight per side) 8-32 x 0 screws provided (see #2 in Figure 1). - Page 13 RS112 Rugged Server Using Crystal Slides To install RS112 with Crystal Slides in an equipment rack, complete the following steps and see Figure 2 below: Loosen adjuster screws. Line up the top and bottom holes on the front & rear mounting ears at the desired level of the equipment rack, and attach to the rack using four (two per side) 10-32 x 0.50 rack...
- Page 14 RS112 Rugged Server Using Jonathan Rails To install RS112 with Jonathan Rails in an equipment rack, complete the following steps below and see Figure 3 on the following page. Attach a bracket (see #6 in Figure 3) to the smooth side of the Jonathan rail that has four or more holes in a row (see #9 in Figure 3).
- Page 15 LOCK MECHANISM (1 ON EACH RAIL) LOCK MECHANISM (2 ON EACH RAIL) FOUR HOLES (2 ROWS OF 2- 4 ON EACH RAIL) Extended Views Closed Views with Brackets Figure 3. Jonathan Rails RS112 Rugged Server User Guide Page of 26...
-
Page 16: Operating The Product
RS112 Rugged Server Operating the Product If the RS112 is part of a rack configuration, refer to the rack guide for more information on connecting to a power source. CONNECTING TO A POWER SOURCE Please see Installing the Product on page 9 for more information. -
Page 17: Maintaining The Product
CHASSIS ACCESS Removing the Cover Ensure the RS112 is powered off and the unit is disconnected from the power source. Remove the screws connecting the top cover to the chassis using a Phillips screw driver. Lift the cover to expose the interior of the chassis. -
Page 18: Chassis Views
RS112 Rugged Server CHASSIS VIEWS: POWER LED POWER SWITCH DRIVE BAY 2 DRIVE BAY 1 USB 1 BD/CD/DVD Figure 4. Front View RS112 GROUND POWER STUD WITH SLOT INPUT WINGNUT I/O PORTS Figure 5. Rear View RS112 The images above may not depict the product received. - Page 19 For detailed information about the X9 motherboard option included in the product, please review the guide at the following link: X9 User Guide See chapter 2-5- Control Panel Connectors and I/O Ports, page 2-13 in document (page 37 in Adobe PDF format). RS112 Rugged Server User Guide Page of 26...
-
Page 20: Expansion/Riser Card Removal And Replacement
RS112 Rugged Server EXPANSION/RISER CARD REMOVAL AND REPLACEMENT Installing a plug-in expansion card requires an appropriate riser card. Contact a Crystal Sales Representative or Technical Support if the system does not include a riser card. Removing and Replacing the Plug-in Expansion/Riser Card Disconnect power source to prevent injury. - Page 21 RS112 Rugged Server CARD CAGE RISER CARD ASSEMBLY RETENTION SCREW CARD RETENTION SCREW CARD CAGE RETENTION SCREWS Figure 6. RS112 Expansion/Riser Card Installation The image above may not depict the product received. RS112 Rugged Server User Guide Page of 26...
-
Page 22: Hard Drive Removal And Replacement
Tighten thumbscrews to secure the drive. Reapply power to the server, rebuilding any RAID arrays as necessary. THUMBSCREW Figure 7. Drive Removal and Replacement The image above may not depict the product received. RS112 Rugged Server User Guide Page of 26... -
Page 23: Memory Removal And Replacement
Press the DIMM into its slot evenly on both ends until it clicks into place. The DIMM release levers will snap into place. The DIMM is properly seated when the release levers have fully engaged. RS112 Rugged Server User Guide Page of 26... - Page 24 RS112 Rugged Server DIMM KEY RELEASE LEVER Figure 8. Installing Memory RS112 Rugged Server User Guide Page of 26...
-
Page 25: Troubleshooting
RS112 Rugged Server Troubleshooting CONTACT TECHNICAL SUPPORT If any problems arise when using the RS112, please contact Technical Support at one of the options listed on page 6. Before calling, please have the following information available to help expedite assistance:... -
Page 26: Available Warranty
LIABILITY IN TORT, OR PRODUCT LIABILITY, ANY DELAY IN MANUFACTURE OR DELIVERY OF EQUIPMENT OR PRODUCT, OR FOR ANY FAILURE OF SELLER TO COMPLY WITH THIS AGREEMENT SHALL BE THE REPAIR OR REPLACEMENT OF THE PRODUCTS AS PROVIDED HEREIN. (REVISED DECEMBER RS112 Rugged Server X9 User Guide Page of 26... -
Page 27: Legal Information
This guide may contain or reference information and products protected by copyrights or patents and it does not convey any license under the patent rights of Crystal Group Inc., nor the rights of others. -
Page 28: Rs112 Rugged Server User Guide Page Of
EACH PRODUCT MANUFACTURED WITHIN CRYSTAL GROUP INC., IS MARKED WITH THE APPROPRIATE CERTIFICATION OR LICENSE SYMBOLS THAT APPLY. IF THERE ARE ANY QUESTIONS ABOUT THE LICENSES AND/OR CERTIFICATIONS THAT CRYSTAL OBTAINS, PLEASE CONTACT A CRYSTAL REPRESENTATIVE AT ONE OF THE OPTIONS LISTED ON THE... - Page 29 RS112 Rugged Server...
