Introduction
M70-D
Digital Moisture Meter with the newest ergonomics design, and its special shape, easy
operating and reading angle make it more beautiful. M70-D is a moisture meter applied in every kind of
industry; it can be used to measure the moisture (%) in the process from raw material to finished products,
and the measured material including wood, bamboo, construction material, paper...etc. And it also can be
used to measure the relative moisture of other materials like food, leather, powder, cloth, ceramics,
cement...etc.
1. Features
□ Digital LCD display with luminescence back-light.
□ Aesthetics protection cap for safe carrying and operating
□ Harden and gloss treatment on display-window for abrasion-proof and long-term clean
□ 5.5% to 99.9% moisture range with DC 0~1V output
□ Stores up to 99 readings, Max./Min average values recalled
□ Auto temperature compensation and internal calibration
□ Auto power off and low battery warning(with audible)
□ Ergonomics design, easy operating, comfortable and durable.
□ CE and RoHS approved
2. Instrument Description
※ Please read the content below for the detail operation and function.
M70-D Digital Moisture Meter
Instruction Manual
○
Protection Cap
1
○
LCD display（with Back-light）
2
○
key
3
○
key
4
○
key（power）
5
○
Signal output
6
○
CAL calibration key
7
○
key
8
○
key
9
○
External probe connecter
10
○
Needle（Electrode for measuring）
11
○
Instrument model no. and S/N. no.
12
○
Battery cover
13
Advertisement
Table of Contents
Related Manuals for Rixen M70-D
Summary of Contents for Rixen M70-D
-
Page 1: Instrument Description
Digital Moisture Meter with the newest ergonomics design, and its special shape, easy operating and reading angle make it more beautiful. M70-D is a moisture meter applied in every kind of industry; it can be used to measure the moisture (%) in the process from raw material to finished products, and the measured material including wood, bamboo, construction material, paper…etc. - Page 2 3. Key Description Function Description LCD display ● Power key Press one time for power on or off (auto power off) to turn on and ● When power off, hold then press process manual operating model. HOLD key operating and →...
-
Page 3: Operating Instructions
4. Operating Instructions A. Preparation A-1 Please check all accessories of the instrument before using： ◇ Main instrument-----------------------------------------NO.M70-D x 1 pc ◇ Protection cap (on the instrument)-- -----------------NO.713M x 1 pc ◇ External needle type probe-----------------------------NO.7021 x 1 pc ◇ Replacement standard needle -------------------------NO.701P/S x 2 pc ◇... - Page 4 C-2 Maximum reading value function（MAX） Press the key twice in the normal model to read the maximum value and the memory location C-3 Minimum reading value function（MIN） Press the key thrice in the normal model to read the minimum value and the memory location C-4 Average reading value function（AVG）...
-
Page 5: Signal Output
needs to adjust the instrument, please operate the instrument as the steps below F-1. When the power is off, hold firstly, and then press to turn on,「CAL」will appear on the display left below and the instrument will make a voice “Be” every 4 seconds, it represents the instrument is in the adjustment model. - Page 6 M70-D Specification: Measuring Range 5.5 ~ 99.9% H2O %WME Resolution 0.1 % Accuracy (at 25℃) ± 1% Wood scale Display Digital dual LCD display,With multi.-function indicator. Sampling Rate 0.3 seconds Wood group scales select from 9 wood groups Data memory 99 readings Analog DC 0 ~ 1V (10 mV / 1%), load >...
