INDEX
A. Introductions -------------------------- 1
B. Features --------------------------------- 1
C. The Panel and Shape ---------------- 2
D. The LCD Display ---------------------- 3
E. Operation Instructions --------- 4 ~ 6
F. Calibration Tables -------------------- 7
G. Precaution ------------------------------ 8
H. Specifications ------------------------- 9
Advertisement
Table of Contents
Related Manuals for Rixen M-700
Summary of Contents for Rixen M-700
-
Page 1: Table Of Contents
INDEX A. Introductions -------------------------- 1 B. Features --------------------------------- 1 C. The Panel and Shape ---------------- 2 D. The LCD Display ---------------------- 3 E. Operation Instructions --------- 4 ~ 6 F. Calibration Tables -------------------- 7 G. Precaution ------------------------------ 8 H. Specifications ------------------------- 9... - Page 2 H. Specifications Measurement range 5.5 ~ 99.9% (Digital LCD Display) (% WME) 1% (difference as the testing Accuracy (at 25C) materials.) Resolution 0.1% Operating Range -10 ~ +50C (with temp. compensated) No. of wood 8 (choose form “MODE” key) calibration scales Sampling rate Approx.
- Page 3 G. Precaution 1. The power supply is 9V Battery, and can option to use AC adaptor. Please notice the power supply when operation. 2. When measuring, please don’t touch the moisture probe, and don’t use the moisture probe and outside moisture probe simultaneously to avoid wrong measuring value.
-
Page 4: Introductions
Just press CAL (Calibration) key and adjust calibration screw to calibration by yourself. M-700 is very suit for different environment, and has temperature compensate function to let reading more accurate, fast and stable. M-700 can application... -
Page 5: The Panel And Shape
C. The Panel and Shape LCD Display MODE & CAL Key Power Switch REC Key H-D Key Moisture Probe Outside Moisture Probe Offset calibration screw AC Adaptor connector DC 9V Battery box - 2 -... - Page 6 F. Calibration Tables (For Wood) Europe Pacific Japan Britain elm Christmas Europe fine-grained Quassia Bodhi tree maple china fir tree tree birch wood The torrid India Camphor White elm Hickory Persimmon Pomegranate zone balsa Japan elm tree tree tree tree tree China fir wood...
- Page 7 Calibration Method: Turn off the meter. Keep the MODE (CAL) key pressed and press key to turn on the power. When display indicate symbol “CAL” to enter calibration Mode. The indication reading should be 18.4% (0.5). If need to calibrate, please use screwdriver to calibrate from right-side of meter.
-
Page 8: The Lcd Display
D. The LCD Display Low battery warns MAX Value Hold Value MIN Value Recording value warns No. of Calibration Table Moisture Value Recording Mode Calibration Mode Manual Power Off - 3 -... -
Page 9: Operation Instructions
E. Operation Instructions 1. Turn On: Press key to turn on the Meter, It will run to set up inside Automatic temperture compensation in few seconds. (display 8888). ※ Meter will be auto turn off after 30 seconds. 2. Manual Turn Off: Keep the key Pressed and press key to turn on the power, The display will indicate symbol “E”... -
Page 10: Calibration Tables
6. MAX, MIN (Recall): After step 5. MAX.MIN.(Record), press .key to stop record function (display indicates “HOLD”). Press key again to read MAX reading (display indicates “MAX HOLD”). Press key again to read MIN reading (display indicates “HOLD MIN”). ※ Press key will delete all readings and return to normal mode (“MAX HOLD MIN”...
