Page 1: User Manual
Avonic AV-CV150 3G SDI to HDMI Converter User Manual Version 1.0 Update notes: Join Avonic linkedin.com/company/avonic twitter.com/avonic1 facebook.com/avonic www.avonic.eu... -
Page 2: Table Of Contents
Congratulations ........................... 3 Safety Notes ............................3 Package contents and Accessories ..........3 Product Overview ................3 Features ............................... 4 Product Description ..........................4 Installation ..................5 Connection Diagram ..........................5 Contact ..................5 Appendix ..................6 Technical Data ............................. 6 www.avonic.eu... -
Page 3: Introduction
AV-CV150-PSU Product Overview The Avonic AV-CV150 SDI to HDMI converter allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on HDMI/SDI displays while ensuring high bit rates of 2.970 Gbit/s to give you fast signal transmission without any loss. For professionals this means that it is easier to distribute and extend your 3G SDI signal while giving you the ability to display your content on HDMI displays owing to the built in HDMI converter. -
Page 4: Features
LOOP OUT: This slot is where you connect with SDI source, In order to send a SDI signal to a display. INPUT: This slot is where you connect the SDI display with an SDI cable for displaying images. Connect it to another SDI to HDMI converter/ extender to extend your signal or connect to multiple displays. www.avonic.eu... -
Page 5: Installation
SDI Monitor TV or Monitor Contact For any questions or suggestions, contact the reseller or the local distributor of Avonic. Find the local distributor on the website of Avonic. For the recent manual or datasheet, look at the Avonic website. -
Page 6: Appendix
Input: AC100 - 240V 50/60Hz Power Supply Output: DC 5V/1A Adaptor (US/EU standards, CE/FCC/UL certified) Power Consumption Operation Temperature 32 - 104°F / 0 - 40°C Storage temperature -4 - 140°F / -20 - 60°C Relative Humidity 20 - 90% RH (no condensation) www.avonic.eu...
