- Page 1 USER MANUAL Avonic CD500 AV-CD500 www.avonic.com • © February 2023 • Version 1.0.6...
-
Page 2: Disclaimer, Contact And Markings
“look and feel” and arrangement of such Content, contained in this Manual is owned, controlled or licensed by or to Avonic, and is protected by trade dress, copyright, patent and trademark laws, and various other intellectual property rights and unfair competition laws. -
Page 3: Ec Declaration Of Conformity
4. The object of the declaration described in point 1 is in conformity with the EMC2014/30/EU 5. Standards EN 55032: 2015/AC: 2016 Class A EN 61000-3-2: 2014 EN 61000-3-3: 2013 EN 50130-4: 2011+A1: 2014 6. Signed for and on behalf of Avonic: Delfgauw, 20th of May, 2021 Martijn van Bodegom, Product Manager... -
Page 4: Important Information
IMPORTANT INFORMATION Liability Avonic will NOT be held responsible for any damage or injury caused by unqualified persons carrying out these tasks, or by not following the instructions in this Manual. Intended Use and Non-Intended Use Installation The following applies to the installation of the Product: •... - Page 5 Symbol Meaning Description Information The information associated with symbol refers to a general remark or a reference to other documentation. Instruction This symbol refers to one or more user instructions. Recycling Specific parts of the Product can be re-used. Acronyms The following acronyms are used in this Manual: High Definition HDMI...
-
Page 6: Table Of Contents
Connecting the components to the CD500................14 Compatible hardware list....................14 MAINTENANCE.............................15 CD500 Maintenance........................ 15 Usage Precautions........................15 TRANSPORT AND STORAGE........................16 DISPOSAL AND RECYCLING....................... 17 TROUBLESHOOTING..........................18 General............................18 Power Issues..........................18 No video output signal over IP or HDMI from the CD500 ............. 18... -
Page 7: Introduction
Avonic CD500. The Avonic CD500 is part of the CamDirector (system) that ® consists of a CD500 hardware unit, two CM70 series cameras and Teacher Tracker software (both separately available). In this Manual, the Avonic CD500 is referred to as the 'Product'. -
Page 8: Safety
SAFETY This chapter contains important safety information regarding the unpacking, installation and use of the CD500. Important Precautions This Product is NOT intended for use where failure of the device could lead to death, personal injury, or severe environmental damage. -
Page 9: Ventilation
• Don’t open the Product and don’t attempt to repair it yourself. Disassembling the Product may damage it or may cause injury to you. • If this Product is damaged, malfunctioning, or if it comes into contact with liquid, contact Avonic or an Avonic Authorized Service Provider. -
Page 10: Product Overview
® Avonic’s Pro-AV solutions. The CD500 can process, analyze and transmit video generated by the two PTZ cameras it controls. The one-of-a-kind AutoTracking module uses locally run machine learning algorithms to offer smart video recording. -
Page 11: Unpacking
• Be careful with the CD500. The CD500 is made of sensitive electronic components that could be easily damaged. Place the CD500 always on a hard and stable surface! Be sure that this surface could carry the weight of the CD500! -
Page 12: Unpacking The Av-Cd500
If this is NOT the case, contact Avonic and stop here. The AV-CD500 should be in its protective foam as follows: 3. Verify that the plastic CD500 bag is sealed. If this is NOT the case, contact Avonic and stop here. 4. Break the seal of the sealed CD500 bag. -
Page 13: Mounting And Installation
It is also possible to mount the CD500 using the delivered mounting shields to a wall. Follow instructions below: 1. The mounting shields are already connected to the CD500. Use the supplied screws (4) and place for every screw hole 2 spacers. The spacer with a cut should be above the spacer without a cut. -
Page 14: Connecting The Components To The Cd500
3. Connect a Ethernet (CAT6a) cable to the ethernet port at the front of the CD500. 4. Connect the supplied power cable and adapter to the PSU port at the back of the CD500. After connecting the power cable and adapter the CD500 will start automatically. The power light next to the Ethernet port will turn ON. -
Page 15: Maintenance
CD500 Maintenance Take the following actions to maintain the CD500: • If you will not be using the CD500 for a long time, turn off the power switch and disconnect the AC powercord of the AC adaptor to the outlet. -
Page 16: Transport And Storage
TRANSPORT AND STORAGE The CD500 must be transported in its original packaging box. Inside the box, it is recommended to wrap the CD500 in the original plastic bag and to place it in the protective foam. Specific guidelines apply to the environmental temperature and humidity when operating and storing the camera. -
Page 17: Disposal And Recycling
Avonic is NOT responsible for personal data left in the settings of the CamDirector as far as this is possible (like IP Addresses, user names, passwords etc.) Delete personal data BEFORE you send the CD500 back to Avonic! or your local distributor. -
Page 18: Troubleshooting
General 1. Turn the CD500 off and on again and check if the problem persists. 2. If the problem persists after putting the CD500 off and on again, restore to the factory default. Power Issues If the CD500 power LED is OFF: 1. - Page 19 Avonic CD500 AV-CD500 © February 2023 • Version 1.0.6 Exportweg 11a • 2645 ED Delfgauw • The Netherlands +31(0)15 7112 712 • info@avonic.com • www.avonic.com...
