7. AR2788S Series Parts List

P/N
39-020 115 VAC 6" FAN
39-021 230 VAC 6" FAN
AR2788SX11 AR2788S/FA1234 TANK FILTER IN HOSE ASSY
AR2788SX29 FILTER BRACKET STRAPS
AR2788SX31 12 VDC SOLENOID CHARGING VALVE OPERATOR
AR2788X14A 1/2 ACME REFILL ADAPTOR
AR2788X14B 1/4 SAE REFILL ADAPTOR
AR2788X16 LOW SIDE GAUGE KIT
AR2788X17 HIGH SIDE GAUGE KIT
AR2788X25 AR2700/AR2788/AR2788S/FA1234/FX134 SCALE PCB
AR2788X30 ONE LB WEIGHT
AR2788X32 15 AMP BREAKER 115 VAC
AR2788X33 10 AMP BREAKER 230 VAC
AR2788X40 6 FT POWER CORD 115 VAC
AR2788X41 6 FT POWER CORD 230 VAC EUROPE
AR2788X45 HIGH PRESSURE SWITCH 450PSI
AR2788X53 HEATER BLANKET IEC
AR2788X57 1/8 GAUGE TUBE/WITH COMPRESSION FITTINGS
AR2788X65 10" WHEEL
AR27XHB115 115 VAC HEATER BLANKET
AR27XHB230 230 VAC HEATER BLANKET
FA1234X13 FA1234/134A VAPOR HOSE RECOVERY TANK
FA1234/134AHOSE,COMP DISCHARGE-DOAIN HEAT
FA1234X18 EX
FA1234/134AHOSE,ASSY,DOA HEAT EX OUT TO HV1
FA1234X19 TEE
FA1234X2 FX134A COMPRESSOR ASSY 115 VAC (sealed relay)
FA1234X21 FA1234/134A HOSE,ASSY,DOA PURGE TEE IN AUX
FA1234X22 FA1234/134A HOSE,ASSY,HV1 TANK VAPOR
FA1234X23 FA1234/134A HOSE,ASSY,FS1 TANK LIQUID
FA1234X24 FA1234/134A HOSE,ASSY,HV1 TEE HV2
FA1234/134A HOSE, ASSY, HV3-OIL DRAIN BULK
FA1234X25 HEAD
FA1234X26 FA1234/134A HOSE,ASSY,LV3-HV2 TEE VAC
FA1234X29 TEMPERATURE SENSOR TANK VAPOR LINE
FA1234X3 FA1234 COMPRESSOR ASSY 230 VAC 50 HZ
FA1234X30 TEMPERATURE SENSOR AMBIENT MAIN PCB
FA1234X32 AIR FLOW SWITCH
FA1234X36 FA1234 1234YF REFILL ADAPTOR
FA1234X37 FA1234 BRASS REGULATOR 80 PSI
FA1234X39 IEC INLET MAIN POWER
FA1234X92 92# TANK KIT FOR ADDITIONAL REFRIGERANTS
FX3030X10 10 PIN WIRE/ IDENIFIER WIRE / SD CARD PCB ASSY
FX3030X11 FX134A SCALE ASSEMBLY
FX3030X12 MAIN POWER SWITCH MOMENTARY
FX3030X13 POWER SUPPLY PCB 65W 12 VCD
FX3030X14 POWER SUPPLY PCB 15W 12VCD
FX3030X15 ONE LB WEIGHT
DESCRIPTION
55
P/N
FX3030X16 PRESSURE TRANSDUCER
FX3030X17 CASTOR W/BRAKE
FX3030X18 FX1234 LO SIDE SERVICE HOSE 10 FT
FX3030X19 FX1234 HI SIDE SERVICE HOSE 10 FT
FX3030X2 OIL DRAIN BOTTLE
FX3030X20 FX134A VACUUM PUMP HOSE ASSY
FX3030X21 FX134A HOSE,ASSY,HV1 VAPOR OUT BH
FX3030X22 FX134A HOSE, ASSY, HV3-OIL DRAIN BULK HEAD
FX3030X23 FX134A HOSE,ASSY,LV4-DOA IN
FX3030X24 4 RELAY PCB
FX3030X25 FX134A OPERATION MANUAL
FX3030X26 FX1234 OPERATION MANUAL
FX3030X27 FX3030 OPERATION MANUAL
FX3030X28 MAIN PCB /LCD ASSY / SD DATA CARD
FX3030X29 FX134A LOW BLOCK ASSY
FX3030X3 SCALE PATCH CABLE BLK
FX3030X30 FX134A HI BLOCK ASSY
FX3030X31 POWER HARNESS IN 6 PIN CONNECOR
HV MAIN POWER HARNESS TO LG 65W POWER
FX3030X32 SUPPLY
FX3030X33 EX AUX POWER HARNESS OUT 8 PIN CONNECTOR
FX3030X34 PRESSURE TRANSDUCER PCB
FX3030X35 ON / OFF POWER SWITCH LIGHT WIRE HARNESS
FX3030X36 USB WIRE HARNESS
FX3030X37 IDENTIFIER WIRE HARNESS
FX3030X38 SD CARN READER WIRE HARNESSES 4 PIN
FX3030X38B SD CARN READER WIRE HARNESSES 5 PIN
FX3030X39 RCA JACK WIRE HARNESS
FX3030X4 PT PATCH CABLE BLUE
FX3030X40 12VDC 15W WIRE HARNESS
FX3030X41 HIGH PRESSURE SWITCH WIRE HARNESS ORANGE
FX3030X42 THERMAL PRINTER
FX3030X43 FLUSH BLOCK HYBRID FX134A
FX3030X44 FLUSH BLOCK HYBRID FX1234
FX3030X45 FLUSH BLOCK HYBRID FX3030
FX3030X46 FLOW SWITCH JUMPER
FX3030X47 IDENTIFIER INTERNAL HOSE
FX3030X48 IDENTIFIER SOLENOID VALVE ASSY
FX3030X49 AIR FLOW SWITCH WIRE HARNESS
FX3030X5 RELAY PATCH CABLE RED
FX3030X50 50# TANK KIT FOR ADDITIONAL REFRIGERANTS
FX3030X6 LOW BLOCK PATCH CABLE YELLOW
FX3030X7 HIGH BLOCK PATCH CABLE GREEN
FX3030X8 FX134A LOW SIDE BLOCK PCB
FX3030X9 FX134A HIGH SIDE BLOCK PCB
DESCRIPTION
