Inspector 5000™ Auto Optic
Calibrating the Unit
After displaying the Calibration screen, press the Select button to begin calibration
GRADE
ENCODE
CALIBRATION MODE
REFLECTANCE = XX%
PRESS SEL TO CALIBRATE
PRESS UP TO RETURN TO SETUP
A=1.115 B=-17.1 GAIN= 5 OFFSET=2
RJS, Minneapolis, MN
Operator's Guide
PROFILE
REPORT
002-7856
10
