“Chapters” in the table of contents to navigate directly to the corresponding page. Section B: Doppler Ultrasonic Velocity Sensors - Only necessary if installing MACE Doppler ultrasonic velocity sensors To return to the table of contents click on the “Contents” button at the bottom of each page.
You must be careful to ensure that the use of this information complies with the laws, rules and regulations of the jurisdictions radio interference in which case the user may be required to take adequate with respect to which it is used. MACE assumes no responsibility for personal or property damage caused by the misuse of this equipment.
Page 4
Typically, velocity is zero along the wall of the pipe and increases to a maximum at or about the centre of the pipe. MACE Doppler ultrasonic velocity sensors receive re ected frequencies from particles moving at these di erent velocities.
Page 5
Installing on a 2” pole Installing on a wall Installing XCi power options Solar panel installation on a 2” pole Installing a MACE mains powered trickle charger Powering the XCi device with an external battery XCi device maintenance Battery maintenance...
Page 6
This manual describes the installation, use and maintenance of a MACE XCi The XCi system typically consists of ve main components: device. There are three MACE XCi devices which are speci cally optimised for 1. The XCi device our three main markets: 2.
Page 8
A communications port is located on the bottom face of the main enclosure. Using a MACE USB data cable (Part No. 850-363) between this port and a PC, users can con gure, troubleshoot and download data from the device using the MACE FloCom software downloadable from www.macemeters.com...
Page 9
MACE recommends that the XCi device be mounted so that the LCD faces The Doppler sensor cable should be looped prior to connecting in a direction away from direct sunlight.
Page 10
3. Follow instructions 3-6 on the previous page for routing the cables through conduit. MACE XCi PRODUCT MANUAL SECTION A: THE XCI DEVICE CONTENTS CONTENTS MACE XCi PRODUCT MANUAL...
Page 11
(for example those found at http://rredc.nrel.gov/solar/old_data/nsrdb/ nuts so that the bracket is secured on the pole. redbook/atlas/ ). As a guideline, for an AgriFlo XCi/FloPro XCi with three Doppler sensors (or an HydroMace XCi with three I/O cards) and 10. Tilt the solar panel so that the active side faces towards the sun (North in...
Page 12
NOTE: When wiring the solar panel either of the ground (-ve) terminals may be used 2. Alternatively, if a DC source other than a MACE charger is used, this is terminated using the same three-pin connector as for the solar panel described above.
Page 13
The solar panel should be cleaned with a wet brush or rag. Do not use steel bristle brushes that may cause damage to the glass of the solar panel MACE XCi PRODUCT MANUAL SECTION A: THE XCI DEVICE CONTENTS...
