Mace MaceAlert Solo User Manual

|
MAS-WA-WDS
User Guide
Wireless Window & Door Sensor
Please keep these instructions in a safe place for future
reference.
Kit contents:
1 Wireless Window & Door Sensor
1 Magnetic contact
1 Double-sided adhesive pad
1 User Guide

1. INTRODUCTION

The MaceAlert™ Solo Wireless Window & Door Sensor consists of two parts, a
transmitter and a magnetic contact. Once this sensor is installed, with the transmitter
fastened to the frame and the magnet to the door or window, the sensor will trigger
and transmit a message to the MaceAlert™ Solo Wireless Alarm Panel when the door
or window is opened.

2. LOCATION

First determine the location of the sensor, which should be placed:
• In the most vulnerable parts of the property rooms or near key entry/exit points
• Away from extreme temperature sources (radiators, ovens, stoves etc.) and large
metal objects that could interfere with the wireless performance
• Away from direct sunlight.
• Where better RF performance can be achieved (if necessary)

3. INSTALLATION AND OPERATION

3.1 P
owering
• Remove the battery cover; insert new batteries noting the
polarity as shown in Fig. 1 and replace the cover.
(Requires 2 x AAA batteries)
w
uP the indow
& d S
oor enSor
