Host Application Objects
Command Details: Get_IM_Record
Category
Extended
Details
Command Code:
Valid for:
Description
This command is sent to the host application when the master (Class 1 or Class 2) asks for an I&M Record
other than I&M0... 4 for slot 0, and for all I&M Records for slots other than 0. If the command is rejected, the
original I&M-request from the PROFIBUS master will be rejected as well.
See also
• Guideline Information & Maintenance functions.
• Command Details
Field
CmdExt[0]
CmdExt[1]
Msg_Data[0]
Msg_Data[1... 3]
• Response Details (Success)
Field
Msg_Data[0... 9]
Msg_Data[10... 63]
®
Anybus CompactCom ™ 40 PROFIBUS DP-V0/DP-V1 Network Guide
10h
Object
Comments
I&M Record index (0... 199)
(reserved, ignore)
Slot number (0... 254)
(reserved, ignore)
Comments
I&M user specific header
I&M Record; I&M parameters associated with the request
